Custom size stainless steel filter mesh

Material: AISI304, AISI 304L, AISI 316, AISI 316L etc.

Mesh count: 8mesh-80mesh. we can also produce the following size:

Normal mesh size:
Plain weave: 0.5X0.5mesh to 635X635 mesh;
Twill weave:20x20mesh to 400x400mesh;
Plain dutch weave:10X64mesh to 80X700mesh;
Twill dutch weave:20x250mesh to 400X2800mesh;
Reversed dutch weave: 48x10mesh to 720x150mesh.
Wire diameter: 0.1mm-0.4mm, other wire dia such as 0.025mm-1.8mm is also available.

Features:
High tension: Much higher tension than common polyester mesh and smooth tension;
Super precision: Uniform wire diameter and aperture with extremely low difference;
Low elongation: Very small elongation of wire mesh at high tension;
High flexibility: The wire mesh will not lose elasticity at extreme tension;
High corrosion resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber.

Usage:

Wire mesh deep processing product is Mainly used for Separation and Filtration,  extensively used in petroleum, chemical industry,

environment protection, mine, airspace, paper-making, electronic, metallurgy,food industry etc.

Widely used for water, air,liquid filter.
