1600 straight knives grinding machine

详情

High precision grinding, advanced practical serrated knife grinder, widely used in serrated blade series；suitable for printing, packaging, paper, plastic, leather, cutter machinery and other industries serrated knife, can be used for grinding and cutting;

ruitometal teeth blade grinding machine parameter:
grinding max length 1600mm     Vertical travel of the workbench 1600mm
Workbench horizontal travel       ( up and down) 150mm/120mm
grinding head max speed 6000rpm
grinding head motor power 380V 50HZ 2.2KW
grinding wheel size: 150/160/180/200/250*32*20mm
weight 1650KG    whole machine size 2800*1100*2000

Key Features of Serrated Knife Grinding Machines:

1. Grinding Length: can easily accommodate 1600mm knives. These machines are designed for industrial knives, including serrated blades, and come with programmable PLC controls for automated cycles.
2. Precision and Automation:  This grinding machine features motorized downfeed and spark-out cycles, ensuring precise sharpening of serrated edges. It also includes a electric magnetic plate for carbide-tipped workpieces, making it versatile for various knife types.
3. Grinding Wheel and Spindle:  Machines typically use thin, tapered grinding wheels to fit into the serrations.
4. Cooling and Dust Collection:  this machine include cooling systems and dust collection motors to maintain optimal grinding conditions and prevent overheating.
