离岸价格
获取最新报价( Negotiable )
|1 Unit Minimum Order
国家:
China
型号:
LW300KV
离岸价格:
( Negotiable ) 获取最新报价
位置:
china
最小订单价格:
-
最小订单:
1 Unit
包装细节:
optional
交货时间:
optional
供应能力:
15 Unit per Month
付款方式:
Other, PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T
產品組 :
联系人 Mr. Ryan
Yangpu, Shanghai, Shanghai
| Item | Specification | Unit | |
| Rated operating load | 3000 | kg | |
| Bucket capacity | 1.5~2.5 | m³ | |
| Machine weight | 10600±200 | kg | |
| Dump clearance at maximum lift | 2770~3260 | mm | |
| Reach at maximum lift | 1010~1210 | mm | |
| Wheel base | 2600 | mm | |
| Tread | 1850 | mm | |
| Height of hinge at maximum lift height | 3830 | mm | |
| Working height(fully lifted) | 4870 | mm | |
| Max.breakout force | 130 | kN | |
| Max.horse power | 95 | kN | |
| Hydraulic cycle time-raise | 5.5 | s | |
| Total hydraulic cycle time | 10 | s | |
| Min. turning radius over tyres | 5165 | mm | |
| Articulation angle | 35±1 | ° | |
| Gradeability | 28 | ° | |
| Tyre size | 17.5-25-12PR | ||
| Overall machine dimension L×W×H | 7050×2482×3118 | ||
| Model | WP6G125E22 | ||
| Emission standards | Emission 2 | ||
| Rated Power/Speed | 92/2300 | kW/rpm | |
| Fuel Tank | 170 | L | |
| Hydraulic Tank | 170 | L | |
| Ⅰ-gear(F/R) | km/h | ||
| Ⅱ-gear(F/R) | 13/30 | km/h | |
| Travel speed | Ⅲ-gear(F) | 24/- | km/h |
| Ⅳ-gear(F) | 40/- | km/h | |
(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
(2)Spare parts:CANMAX is dedicated to provide our clients
with genuine spare parts with the highest quality,exact fitness
and appropriate function.
(4)Training: CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.
(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.
| 国家: | China |
| 型号: | LW300KV |
| 离岸价格: | ( Negotiable ) 获取最新报价 |
| 位置: | china |
| 最小订单价格: | - |
| 最小订单: | 1 Unit |
| 包装细节: | optional |
| 交货时间: | optional |
| 供应能力: | 15 Unit per Month |
| 付款方式: | Other, PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T |
| 產品組 : | Wheel Loader |
