Tungsten Carbide Grades (Properties and Application)
|
Grade |
WC% |
Co/Ni% |
Physical and mechanical properties |
Grain size μm |
Recommended application |
||
|
Density g/cm3 |
TRS N/mm2 |
Hardness HRA |
|||||
| ZG01 | 100 | 0 Co | 15.3-15.5 | 1200 | 95.5 | 0.3 | Ultra high hardness, high wear resistance, corrosion resistance, with certain damage resistance |
| ZG04X | 96 | 4 Co | 15.0-15.2 | 1600 | 92.8 | 0.8-1.0 | Suitable for wire drawing die, non-ferrous metal wire tensile wear-resisting parts |
| ZG06 | 94 | 6 Co | 14.8-15.1 | 2500 | 90.0 | 1.2 |
Good wear resistance, good compression resistance, suitable for wear resistance and high pressure resistance parts, good thermal rigidity |
| ZG06X | 94 | 6 Co | 14.8-15.1 | 2400 | 91.5 | 1.0 | |
| ZG06A | 94 | 6 Co | 14.8-15.1 | 2150 | 92.5 | 0.6-0.8 | |
| ZG08 | 92 | 8 Co | 14.6-14.9 | 2700 | 89.0 | 1.2-1.6 | Good general performance, used for usual wear - resistant parts, molds, general tools, etc |
| ZG10.2 | 90 | 10 Co | 14.3-14.6 | 3800 | 91.8 | 0.7 | Sub-fine tungsten carbide particles, good general performance |
| ZG10X | 90 | 10 Co | 14.3-14.6 | 4000 | 92.2 | 0.6 | Ultra fine tungsten carbide particles, excellent heat resistance |
|
ZG11 |
89 |
11 Co |
14.3-14.7 |
2800 |
88.5 |
1.2-1.6 |
Anti-wear, anti-erosion, good comprehensive mechanical strength, suitable for wear-resistant parts in the petroleum, chemical and mechanical industries. |
