离岸价格
获取最新报价750 ~ 950 USD / Piece
|1 Piece Minimum Order
国家:
China
型号:
ST10
离岸价格:
750 ~ 950 USD / Piece 获取最新报价
位置:
-
最小订单价格:
750 per Piece
最小订单:
1 Piece
包装细节:
box, handstrap, adapter, carton
交货时间:
5-20days
供应能力:
10000 Piece per Month
付款方式:
PayPal, T/T
產品組 :
联系人 Mr. gavin
xixiang, Shenzhen, Guangdong
| Type | Details | Descriptions | ||||
| Product Form | Product Form | Straight Plate | ||||
| Dimensions | 272*195*22mm | |||||
| LCD | Screen Size | 10.1' 16:10 | ||||
| Screen Resolution | 1280*800 IPS | |||||
| TP | Touch Module | 10 Point Capacitive | ||||
| Battery | Type | Lithium-ion polymer battery, | ||||
| Capacity | 3.7V/10000mAH,pluggable battery | |||||
| Endurance | 8 Hours | |||||
| System hardware configuration: | ||||||
| Type | Details | Descriptions | ||||
| CPU | Type | Intel Baytrail-T(Quad-core ), Z3735F/G | ||||
| Speed | 1.33Ghz-1.86GHz | |||||
| GPU | Type | Intel HD Graphic(Gen7) | ||||
|
Multi-media (Hardware decoding) |
Photo Viewer | BMP, JPG, GIF, PNG | ||||
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) | |||||
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | |||||
| RAM | Capacity | 1GB/2GB DDR3L | ||||
| ROM Flash | Capacity | 32GB (16GB/64GB/128GB optional） | ||||
| Camera | Front | 2.0MP | ||||
| Rear | 2.0MP/5.0MP（optional） | |||||
| Speaker | Size | Built-in 8Ω/0.8W speaker x 2 | ||||
| G-sensor | Built-in | Gravity acceleration sensor | ||||
| Network Connections: | ||||||
| Type | Details | Descriptions | ||||
| WIFI | WIFI module | WIFI 802.11(2.4G+5.8G)+BT 4.0 | ||||
| 3G | External | 3G Dongle (WCDMA/EVDO/TD-SCDMA optional) / built-in WCDMA | ||||
| Ethernet Network | MiNi USB switch to Ethernet Network | Supportive RJ45 | ||||
| Interface Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Memory card socket | External memory | Support SDHC/SDXC | ||||
| USB interface | Data transfer supportive | USB 2.0 | ||||
| Headphone jack | Music output | ∮ 3.5mm standard headphone jack | ||||
| DC connector | Power | ∮ 3.5MM power connector | ||||
| HDMI interface | Video output | HDMI 1.4a | ||||
| Keyboard | Input device | Wired / Wireless Supportive | ||||
| Dock station | Input device | DC,RJ45, RS232,USB 2.0*2, | ||||
| Necessary Accessories: | ||||||
| Type | Details | Descriptions | ||||
| Power adapter | Standard Configuration | 5V/3A | ||||
| USB patch cord | Standard Configuration | Standard USB to Micro USB | ||||
| Type | Details | Descriptions | ||||
| Operating System | Operating system version | Windows 8.1 | ||||
| Language | Multi-language supportive | |||||
| HTML5 | Supportive | |||||
| Optional module RFID | ||||||
| Type | Details | Descriptions | ||||
| RFID(13.56M) | RF Frequency | 13.56MHz support 14443A/14443B/15693/18092/mifare protocol | ||||
| chipset setting mode | Card reader mode（without SE,do not Android card reading function） | |||||
| Interface | RS232(TTL) | |||||
| Voltage range | 3.3V | |||||
| Working current | < 150mA | |||||
| standardby current | < 1mA | |||||
| Baud rate | 9.6 to115.2 kbps | |||||
| Work range | < 10cm | |||||
| Main function | Data interchange between MID and NFC, provide API interface based on JAVA layer | |||||
| low power control comsuption | ||||||
| card can be read by ISO14443A/B, ISO15693 protocol | ||||||
| RFID antenna | Internal：Magnetic FPC | |||||
| Optional module Unicorecomm | ||||||
| Type | Details | Descriptions | ||||
| BDS/GPS dual mode | Voltage range | 2.7~3.3`VDC | ||||
| power comsumption | 120mA | |||||
| frequency | 1559~1577MHZ | |||||
| positioning accuracy(RMS) | 2.5m CEP(a level when dual system) | |||||
| Standing wave ratio | < 1.5 | |||||
| RMS | GPS/GNSS:0.1m/s , Beidou:0.2m/s | |||||
| first-positioning time | cold start time :32S, hot start time:1S, recapture time :< 1s | |||||
| sensetivity | Tracking: Beidou-160dBm, GPS-160dBm ; Capture: Beidou-145dBm, GPS-147dBm | |||||
| data updating rate | 1Hz( can update to 5Hz) | |||||
| Data Interface | NMEA0183(compatible with Beidou ) | |||||
| Unicore protocol | ||||||
| Dimension | 16.0X12.2X2.4mm | |||||
| Operating temperature | -40 ℃- 85 ℃ | |||||
| Optional module Taidou Beidou | ||||||
| Type | Details | Descriptions | ||||
| BDS/GPS dual mode | Catch sensitivity | sensitivity： -144 dBm | ||||
| Tracking sensitivity | sensitivity： -159dBm | |||||
| cold start time | < 35s | |||||
| Positioning accuracy(RMS) | < 5m | |||||
| Working voltage | 3.0V-3.6V | |||||
| power comsumption | < 65mA | |||||
| frequency | support BD2 B1 and GPS L1 frequency points | |||||
| 3 type working mode | single BD2 B1 | |||||
| single GPS L1 | ||||||
| BD2 B1/GPS L1 dual working mode | ||||||
| operating temperature | Working temperature: -40 ℃ 85 ℃ | |||||
| Dimension | 12.5mmX18mmX2.0mm | |||||
| Optional module Fingerprint identification | ||||||
| Type | Details | Descriptions | ||||
|
Fingerprint module |
CPU | Inner core：Cotex-M3 （108MHz main frequency、1M Flash Memory、96KB SRAM） | ||||
| fingerprint collector | Array of semiconductor fingerprint sensor：FPC1011 | |||||
| registigation capacity | 2000 fingerprints | |||||
| FAR | < 0.001 %（Security Level 3 ） | |||||
| FRR | < 0.1 %（Security Level 3 ） | |||||
| way of comparison | 1:N and 1:1 contrast | |||||
| size | 498 Byte | |||||
| saf level set | Level 1 to Level 5，Default：Level 3 | |||||
| processing speed | fingerprint recognized time< 0.45s；1:N （when up to the capacity 3000）< 1.5s | |||||
| telecom interface | UART,3.3V-TTL electric level | |||||
| Serial communication parameters | Baud rate: 9600、19200、38400、57600、115200（BPS）Default:115200bps | |||||
| working voltage¤t | DC3.3V-DC6V；< 100mA | |||||
| Operating condition | working temperature：-10 ℃- 60 ℃；relative humidity：20% 80% | |||||
| Optional module 1D Barcode module | ||||||
| Type | Details | Descriptions | ||||
|
1D Barcode module |
optical position | 5mil | ||||
| scan speed | 50/s | |||||
| scan angel | 53°+3°/-3° | |||||
| wake-up time | < 10ms | |||||
| working current/peak current | 165mA | |||||
| power supply | 45mA | |||||
| Domancy current | 115uA | |||||
| Operating voltage | DC3.0V-DC3.6V | |||||
| Symbol system |
UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code
128,GS1-128,ISBT
128, Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11 |
|||||
| Operating condition | working temperature：-20 ℃- 50 ℃； relative humidity：5%95% | |||||
| Optional module 2D Barcode module | ||||||
| Type | Details | Descriptions | ||||
|
2D Barcode module |
optical position | 1280*800；5mil | ||||
| scan speed | 50 times/s | |||||
| scan angel | 42° broad；28° high | |||||
| wake-up time | < 10ms | |||||
| working current/peak current | 280mA/400mA | |||||
| power supply | 45mA | |||||
| Domancy current | 15mA | |||||
| Operating voltage | DC3.3V+/-0.3V | |||||
| Symbol system |
PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse |
|||||
| Operating condition | working temperature：-20 ℃ 50 ℃； relative humidity：5%95% | |||||
|
Features:1.Support Windows 8.1/Android 4.4.4 dual
OS; 2.Support all size standard USB2.0 jack; 3. Support Docking extending charge ; 4.Support RFID(13.56M); 5.Support BDS/GPS dual navagation; 6.Support 1D barcode/2D barcode scan; 7.Support Fingerprint recognition. 8.Support water/dust/drop proof IP65 9.Support 10000mAh big power battery 10.Support the 3rd Generation Corning Glass touch screen 11.Support 400 Lumens highlight LCD 12.Android OS support NFC 13.Support tie and back to carry. |
||||||
| 国家: | China |
| 型号: | ST10 |
| 离岸价格: | 750 ~ 950 / Piece 获取最新报价 |
| 位置: | - |
| 最小订单价格: | 750 per Piece |
| 最小订单: | 1 Piece |
| 包装细节: | box, handstrap, adapter, carton |
| 交货时间: | 5-20days |
| 供应能力: | 10000 Piece per Month |
| 付款方式: | PayPal, T/T |
| 產品組 : | rugged tablet |
