Parameters
1. Rated frequency: dc
2. Rated voltage: DC12V
3. Standby power: < 500 m/W
4. Whole machine power: <100 W
5. Temperature control scope: 15-18 ℃
Appearance and structure:
1. The control board printing "shall be complete, clear.
2. The plate on the show part of show for aΦ 3.0 red LED display compressor ERRO signal, aΦ 3.0 green/orange double color lamp instructions compressor open/stop state, a four 8 period of blue-ray digital pipe display the temperature in the cabinet and thermal resistor (NTC) physical state and other information.
Input:
1. A temperature sensor B = 3435, 25 ° / 10 K.
2. 1 hall switch detection.
3. The 4 s detection.
4. 1 channel dc voltage detecting (for ABS voltage protection).
Output:
1. 2 channel output compressor control (top gear and lower gear).
2. 1 channel LAMP lighting output (LED lights, four LED lights).
3. 1 channel internal fan output control (fan current about 300 mA).
4. 1 channel relay output control.
Function is introduced:
A. master control board
1, digital pipe specifications: 30 * 14 mm, blue-ray digital tube.
2, 4 s: POWER, SET, UP and DOWN.
(1) POWER: as a "POWER" , switch a machine's switch machine state.
ON state: POWER lights up, start refrigeration mode.
OFF state: no
shows, POWER lamp, into standby mode.
