Specification:
|
Dimension
|
55*33*5.9 mm
|
|||||||
|
LED No
|
4 pcs 5050 SMD LED
|
|||||||
|
Voltage
|
Input 12VDC
|
|||||||
|
View
angle
|
120 degree
|
|||||||
|
Current
|
80mA
|
80mA
|
80mA
|
80mA
|
80mA
|
|||
|
Watts
|
0.96
|
0.96
|
0.96
|
0.96
|
0.96
|
|||
|
Lumen
|
80-88
|
10
|
40
|
14
|
16
|
|||
|
Color
|
White
|
Blue
|
Green
|
Yellow
|
Red
|
|||
|
Cover
|
Milky white ABS&Epoxy
|
|||||||
|
IP rate
|
IP65
|
|||||||
|
Working
temp
|
-20～+60℃
|
|||||||
|
Max
connection
|
20 pcs per a string
|
|||||||
|
Life
|
50,000 hrs. Lumen *:*%@********************> |
|||||||
|
Warranty
|
36 months
|
|||||||
|
Certificate
|
CE:BTRE0708181359 / RoHS: BTRS0708310889 |
|||||||
|
Part
No
|
MA-4W50
|
MA-4B50
|
MA-4G50
|
MA-4Y50
|
MA-4R50
|
|||
1. Adopt TOP5050 SMD LED, no light spot, with a low lumen recession and good consistency.
2. With a low power consumption and high lumen value, a long life-span, maintenance-free.
3. With a plastic injection technique for outer cover, this unique structure grants a better cooling effect.
6. Adopt series-parallel connection circuit, 20Pcs for 1 string, each module could be singled out.
This product is applicable for 8-20cm glowing character,
advertisement board, light box or local lighting.
Dimension
Diagramm.(Unit:mm)
| 国家: | China |
| 型号: | MA-4W50 |
| 离岸价格: | 0.1 ~ 0.4 / Piece 获取最新报价 |
| 位置: | - |
| 最小订单价格: | 0.1 per Piece |
| 最小订单: | 500 Piece |
| 包装细节: | Carton box |
| 交货时间: | 5 DAY |
| 供应能力: | 1000000 Piece per Month |
| 付款方式: | T/T, Western Union |
| 產品組 : | led module |
