automatic bagging machine

详情

Automatic bagging machine, automatic packaging machine, filling machine.
Brand:BPE

Original:shanghai

Weight units, sealing machine, stitching machine, wediing machine.

It is Automatic packaging system, automatic bagging machine, Full Automatic Packing Machine, automatic feed packing machine, automatic bagging palletizing machine, automatic packing line that applicable for packing granular or particulate materials such as feed, grains, rice, flour, starch, wood pellet, animal feed, pet food, mineral powder, ore fines, metal granule, feed pellets, dog feed, cat litter, fuel pellets, etc.

And also the automatic robot palletizing machine for stacking on pallet and pallet stretch wrapping machine are optional for the complete net weight type automatic packaging line system.

Main Component:

1. Automatic quantity-fixed balance                  2.Automatic bag-supplying and weighing filling section

3. Optional section such as air compressor       4.Automatic bag-clamped section

5. Automatic belt conveyor                                6.Automatic sewing or sealing machine

7. Automatic bag-backwards section                 8. Automatic robot palletizer  for stacking bags on pallet

9. Automatic online pallet stretch wrapping machine for option

*0. Electrical PLC instrument control cabin

Characteristic:

1. Picking bag, feeding bag, bag placing, filling material, weighing, sewing or sealing bag, bag-backwards and bag transmission are finished completely automatically. Optional automatic palletizing, stretch wrapping.

2. Adopting PLC to guarantee the reliability of control

3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight

4. Adopting touch screen with trouble display and help system for easy operation.

5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.

6. The sewing stitching / sealing machine is an imported NEWLONG brand machine.

 Main Technical Parameter:

Model: ABC

Packing Scope: 5~*0, *0~*5, *5~*0 (KG) (adjustable)

Weight Accuracy: ±0.2%FS

Packaging Material: Open mouth bag

Bag Size: adjustable as per different weight

Air Pressure: 0.6 (Mpa)

Air Consumption: 0.7 (m3/min)

Power: 8~*6 (KW)

Total weight: ****0 (KG)
