Application
This
machine is widely sued for unit operation of different material in
such industries as pharmaceutical industry, chemical industry and
food industry etc.
Basic Working Principle
It
has such characteristics as cross and mutually vertical state in
space, and mixing drum controlled by Y-type universally-jointer
drive and passive shaft. If the drive shaft turns around, the
mixing drum will set in rotation, meanwhile setting in
multi-directional oscillation at 4 times autorotation speed.
Under the actions of diffusion, flow and shearing due to frequent
and rapid rotation, material are mixed together. Besides, the
material are mixed under the rotation of the mixing drum without
centrifugal force, which brings slow-down in gravity segregation
and gives guarantee that mixture can fully meet the requirements
on the condition of mixing them for a short time.
Performance
a.
Featured with distinctive design, reasonable manufacture, lower
noisy, high uniform, mirror polished drum wall, fully mixing,
easy to fully clean and charge and discharge, no cross
contamination good appearance in design.
b.
Three-dimensional movable mixer has particular function in
motion, so to say, special motion directions such as rotation,
intersection, up-side-down, tumbling and etc.
c.
During operation, all material in the mixing drum can be in
self-rotation and diffusion under both rotations without
centrifugal force and be free of such phenomenon as gravity,
segregation, separation and accumulation
d.
Control device and main machine are designed in separate cabinet,
which can ensure high safety during operation. Frequency speed
control and butterfly valve specially designed ensures high
tightness, free leakage. (Other blender has only one main machine
with operating panel hereon and its running speed is invariable
by one reducer motor)
e.
Simplification in installation and maintenance, long service
life, its mixing time is short within 0.5-2mins per batch. Its
height is low and rotating space is small, and loading capacity
is high up to 85% (Other blender only can reach
40-60%)
f.
This equipment adopts the speed control by both inverter and
reducer integrated. Its design is equipped with high sealing
butterfly valve and automatic locking device to ensure no powder
leakage. (Other machine is operated only by stepless motor which
cant ensure stability during operation at variable working
speed.)
| 国家: |
China |
| 型号: |
HD-200
|
| 离岸价格: |
7000 ~ 23000 / Unit ( Negotiable ) （面議）
获取最新报价
|
| 位置: |
Zhejiang,China |
| 最小订单价格: |
7000 per Unit |
| 最小订单: |
1 Unit |
| 包装细节: |
wooden box |
| 交货时间: |
30 days |
| 供应能力: |
1 Unit per Month |
| 付款方式: |
T/T, L/C |
| 產品組 : |
Raw material handling
|
