Brick Making Machine

详情

Forming machine rack: Main frame adopt high-strength steel and special welding technology, extremely robust.
Guidance performance: employing super high-strength steel plated with chrome on its surface enabling its terrific anti-torque capability and wear-resistance capability.
Mould pressure head: synchronous drive of electromechanical system and hydraulic system enabling a small error among blocks at the same plate.
Distributor: The machine employ sensor-hydraulic proportion drive technology , along with ***-degree high-speed rotary feeding system, the mechanism can creates massive centrifugal force to enable rapid and even feeding; and this is especially favourable for thin-walled and multi-hole blocks.
Vibrators: electro-hydraulic driving technology and multi-source oscillatory system, computer-controlled hydraulic drive generated vertical companions vibration, frequency, amplitude adjustable to achieve low-frequency feeding, high frequency molding works, different raw materials obtained by vibration The real effect of vibration acceleration up to *7.5g/m2.
Control systems: human-computer interface, adopting Japan's Mitsubishi electrical appliances, *0 years experiential control program, easy to operate, powerful memory are equipped for upgrade .
Store and feeding device: materials supply is controlled by computer, which can avoid internal pressure by external factors and can ensure even feeding, in this way the strength error of products can be reduced to a minimum level.
Raw materials: sand, gravel, cement, fly ash, slag, steel slag, coal gangue, ceramsite, perlite and other industrial waste.
Blocks can be produced: a variety of exterior wall blocks, interior wall blocks, decorated wall blocks, floorslab, berm block, but also the production of interlocking pavement blocks and curbs and other block. With secondary the fabric institutions also produce color pavers.
Suitable for: Customer who need high-quality equipment, high-productivity, high-strength product, and a variety of different concrete products.
Hydraulic system: Integrated high-pressure hose is employed here with ease of installation; electro-hydraulic flow speed control valve are used to moderate working pressure and flow rate accurately and steplessly according to work demands , in this way can save energy, ensure the cycle time and reduce the rigid impact.

Remarks:
a.    Guarantee period: Within one year quality guarantee after operation normally.
b.    After-sales service:
    We can provide you Ground plot upon the information of your land.
    We can send one technician for installation, debugging and training, buyer afford the round-trip tickets, food, accommodation and allowance $*0 per day, the process will last about a week.
    Or you can install the equipments by yourself under our delicate instruction.
c.    Land, Labor, pallets required:
    Land : about ***0m2 (the whole plant).
    Manpower and equipment needed. **7worker, One forklift, one 3 ton wheel loader
    Pallets: ***0 pieces at least
