Casting Machine

详情

 The four-wheel continuous casting machine is made up by up & low casting ladle, gravity flow adjust device, crystallizing wheel and gearing device,pinch roller device, steel belt greasing device, bridge approach and tension device, ingot picker device, both inside and outside cooling device, steel belts and so on.
    The melting aluminum liquid flows into the up casting ladle by the launder of the holding furnaces. The floating stopper controlled by the gravity can control the flow rate of the aluminum liquid that is flow into the low casting ladle. The aluminum liquid is casting from the low casting ladle by level to the cavity which is formed by crystallizing wheel(H type) and sealing steel belt. The cooling in every sides ensures the crystallizing cast ingot be dense and even. Its easy for the inner and outer cooling rotated out from the crystallizing wheel, and its convenient for the cooling waters adjustment and equipments maintenance. All nozzles are made of stainless steel, with cooling water pressure shows, flow adjustment and pneumatic tension from steel belt (adjustable). The supporting axis of the crystallizing wheel is equipped with an internal cooling device, which allows 0.2 ~ 0.5 MPa cooling water to pass through. The cooling water sprays on the internal surface of the crystallizing wheel by the nozzles. There are three districts for inner cooling, and three for outer and side cooling, through which the aluminum liquid cools down gradually and be solidified into aluminum cast ingot.
