Computer-controlled automatic slitting machine

详情

LS****0 Computer-Controlled Automatic Slitting Machine This machine is suitable for slitting and rewinding of roll materials such as BOPP, OPP, PET, CPE, PVC, and paper fabrics. I. Performance Features and Configuration 1. This machine is a vertical slitting machine with the unwinding and rewinding rolls located at the front and back of the machine. It features an integrated control panel for flexible and convenient operation, and the main motor is controlled by a variable frequency drive. 2. The unwinding tension is controlled by a magnetic powder brake (*0kg/m), and the rewinding tension is controlled by two magnetic powder clutches (*0kg/m). 3. It is equipped with a waste edge blowing device (0.*5KW). 4. The unwinding roll has automatic edge correction controlled by a hydraulic cylinder. 5. The material length is automatically calculated and set, and the machine will automatically stop at the set length. 6. The cutting blade assembly is manually controlled, with *4 blades (8 long blades, 6 short blades). 7. It has 3 press rollers. 8. The unwinding roll uses two ?*6 pneumatic expanding shafts, and the rewinding roll uses two ?*6 segmented pneumatic expanding shafts. 9. The main traction roll is controlled by pneumatic pressure, with manual control, and the transmission guide roll is balanced and dynamically adjusted. *0. The rewinding roll supports are gear-driven (no universal joint is used for high-speed rewinding). II. Control System 1. The main motor is controlled by a variable frequency drive. 2. The automatic integrated edge correction system is controlled by a photoelectric sensor. 3. The rewinding tension is controlled by a taper, and the unwinding tension is automatically controlled to maintain constant tension. 4. The entire machine is controlled by a programmable logic controller (PLC). 5. The operation interface is a 7" color touch screen. III. Technical Specifications 1. Maximum diameter of the slitted roll: ?**0mm. 2. Maximum width of the unwinding roll: ***0mm. 3. Width of the slitted roll: ******0mm. 4. Diameter of the rewinding roll: ?**0mm. 5. Slitting speed: *****0m/min. 6. Slitting accuracy: ≤±1mm. 7. Main motor: 7.5KW. 8. Power supply: **0V/AC *0Hz (three-phase four-wire). 9. Dimensions: L*W*H (***0****0****0mm). *0. Weight: ***0kg.
