Gauge: 5G、7G、9G、*0G、*2G、*4G、*6G
Knitting width:*0”,*6”,*8”,*6”,**0”
Knitting Speed:Max 1.2M/Sec. Knitting speed depends on
gauge, yarn and knitting condition.
Yarn Carrier:Two side interchangeable carrier, and feed
yarn vertically, Main 6 carriers.
Cam System:High and Low butt needle with High and Low butt
jack. Knitted 3 sections Semi-jacquard pattern.
Stitch Density:stepping motor control *0~*9 stitch density
selectable.
Racking:6 Levels to left or right 1G,2G,3G,4G at one time.
Fabric Take-Down:Torque motor control, High & Low
speed adjustable.
Drive System:AC invert motor, command by timming belt,
reciprocating movement, variably adjustable speed.
Top Tension:New type electronic top tension. Big and small
yarn knot filterable. (Automatic slowing down by 1K for small
yarn knot)
Fluorescent Lamp:Inside safety cover and take-down.
Operation Lamp:Green: NOrmal Operation
Yellow: Artificial Stop Red: Abnormal
Stop.
Control System:Computer control with 7"LCD display.
Command simple and easy to operate.
Data Access:Edit program on machine directly and access
program by *2K USB port memory or by main memory.
Stop Motion:Yarn break, knot, over-losse yarn tension,
fabric drop out, wraparound check, floating knit, needle break,
piece count, motor overload, voltage overload.
Power:Single phase AC
**0V, 1/2HP Motor (0.*7KW), *0/*0HZ
| 国家: |
Taiwan |
| 型号: |
AS-318J
|
| 离岸价格: |
（面議）
获取最新报价
|
| 位置: |
- |
| 最小订单价格: |
- |
| 最小订单: |
1 set |
