Copper-Aluminum composites sheets By HongKong Trenda Co., Limited,

Copper-Aluminum composites sheets

离岸价格

获取最新报价

( Negotiable )

1 Ton Minimum Order

国家:

China

型号:

离岸价格:

( Negotiable )（面議）获取最新报价

位置:

China

最小订单价格:

最小订单:

1 Ton

包装细节:

交货时间:

供应能力:

20000 Ton per Year

付款方式:

T/T

產品組 :

Copper-Aluminum Bimetal sheets

产品规格

Brand Name: Trenda
Application: new energy vehicles, lithium batteries, Photovoltaic, power equipment, electricity, heat transfer
Thickness: 0.05-20mm
Grade: A grade
Cu (Min): Copper and Aluminum
Alloy Or Not: Non-alloy
Ultimate Strength (â‰¥ MPa): 90

详情

Copper-Aluminum bimetals VS pure Copper: lower density, larger volume, lower cost.

Our Copper-Aluminum Bimetal Composites material is a plating of copper on aluminum. The two metals are combined together through our patented technology which we called Oxygen-free Semi-molten rolling compound technology. This technology solves the technical problems of oxidation and eutectic of copper-aluminum composite. Our composites materials are tested in many ways and proven over many years as a replacement material for pure copper in some applications.

Compare to pure copper material, Copper-Aluminum Bimetal Composites materials advantages are below.

1. Cost down much: less copper materials, greatly reduce the cost by about 40%-50%.
2. Lightweight: the density of Copper-Aluminum Composites is only 37%-40% of pure copper, greatly reduce the weight by about 50%.

Copper-Aluminum Bimetal Composites strips Features

1. Dimensions and allowable tolerances of copper-aluminum composite materials

Sheet1: Strip thickness and width and allowable tolerances  (Unit：mm )

Serial	material code	Name	base value	allowable tolerances
1	TY-DC0001	thickness	3.8mm	+0.15/-0
2		Copper layer thickness	1.3mm	±0.05
3		Aluminum layer thickness	2.5mm	/
4		Width	40~145	+0/-0.3
5		Length	/	/
6	TY-DC0002	thickness	3.9mm	+0.1/-0.05
7		Copper layer thickness	1.3mm	±0.05
8		Aluminum layer thickness	2.6mm	/
9		Width	40~145	+0/-0.3
10		Length	/	/

2. Mechanical properties of copper-aluminum composites

2.1 Vickers hardness of copper-aluminum composites
Sheet2: Vickers hardness of copper-aluminum composites

Metal Model	Lt	Copper surface hardness	Aluminum surface hardness
T2/1060	H18	/	35~45

2.2 Room temperature pull-up performance
Sheet3: Longitudinal tensile properties of composites at room temperature

Metal Model	Lt	depth/mm	tensile strength Rm/MPa	Elongation
T2/1060	H18	≥3.8	≥150Mpa	≥10

2.3 Peel strength≥25N/mm

2.4 Compound rate：100%

The widely used copper-aluminum composite material concentrates the advantages of copper and aluminum, which not only has the advantages of copper such as high electrical and thermal conductivity, low contact resistance and beautiful appearance, but also has the advantages of light weight and corrosion resistance of aluminum. Therefore, Copper-aluminum composite materials are widely used in new energy vehicles, lithium batteries, Photovoltaic, communication base station, power equipment, electricity, heat transfer, and other industries.

Copper-Aluminum Composites strips/sheets can be made as Copper-Aluminum Composites transition busbar, lithium battery connecting terminals,Copper-Aluminum Composites heat sink,Copper-Aluminum Composites filter cover for communication base station,etc.

Our products are hot sold to more than 20 provinces across the country, and also exported to The European Union, South Korea, Japan, USA, and other countries.

Advantages of our Copper-Aluminum Bimetal Composites materials :
1. Lower Weight due to lower density.
2. Lower cost due to larger volume.
3. Goodthermal/electrical conductivity, Highly corrosion-resistant.
4. Good mechanical properties, easy for cutting/punching/bending/drilling, etc.
5. Simpler processing, good for Mass-production.
