离岸价格
获取最新报价|
1 Set Minimum Order
国家:
South Korea
型号:
GL-70(G, L, LL, KL type)
离岸价格:
位置:
-
最小订单价格:
-
最小订单:
1 Set
包装细节:
2 x 40ft container
交货时间:
90 days
供应能力:
10 Set per Year
付款方式:
-
South Korea
联系人 Mr. Young-Hwan
Street: 235-1, Nae-dong, Ojeong-gu,, Bucheon-Si, Gyeonggi-do
|
[ Greetings
]
We, Mijin Engineering Co., is one of leading manufacturer and specialist in Korea in the field of fin tube machine base on rich experiences with high technologies. Wd are supplying our best quality products Heat Exchanger to global customers with competitive power rates.
Now, we are expandig of our business scope to local
and foreign countries market with pratical design,
standard parts, easy operation and others. We all fo
the Mijin Engineering Co. executives and staff are
not satisfy about present situations and we are more
trying to be a lovely enterprise in future by
developing innovative technologies and providing
high
quality products. Thanks. |
| Main body | 2,100(L) x 1,000(W) x 1,500 (H) |
| Over all lin size | 33,000(L) x 4,000 (W) (Excluded electronic pannel) |
| Input / Output Devices | 15,000(L) / 15,000(L) (Respectively) |
| Total weight | 6.5 Ton |
| Main motor | 50 HP |
| Total Electric consumption | 38 KW |
| Bare tube O.D | 15.875mm 19.05mm 21.7mm 25.4mm 31.75mm 38.1mm 50.8mm |
| Fin per Inch ( FPI ) | 6 FPI ~ 11 FPI |
| Height of Fin | 6.35 mm ~ 19.05 mm |
| Materials of Tube | Carbon steel, Stainless steel, Titanium |
| Materials of Tape |
Aluminum ( A1050, A1060 ), copper |
|
|
| Materials | Carbon steel, Stainless steel, Titanium |
| Ooter size | Φ25.4mm ~ Φ50.8 mm ( ASTM -179 ) |
| Length | 15,000 (L) ( extendible ) |
| Min length | 3,000 (L) |
| Material | A1060, A1050, A1100 |
| Thickness | 0.4 ~ 0.45mm |
| 国家: | South Korea |
| 型号: | GL-70(G, L, LL, KL type) |
| 离岸价格: | 获取最新报价 |
| 位置: | - |
| 最小订单价格: | - |
| 最小订单: | 1 Set |
| 包装细节: | 2 x 40ft container |
| 交货时间: | 90 days |
| 供应能力: | 10 Set per Year |
| 付款方式: | - |
| 產品組 : | Embedded Fin Tube Machine |
