Mechanism related

uThe output cable of encoder and power cable can not be fixed together or putted in same tube. The output

ucable should also be far from the switchboard to avoid disturbing . The cable should be shielded.

uCareful check should be taken before starting the machine, the product instruction should be matched with

uthe encoder model, wire connection should be correct , wrong connection will damage the internal circuit.

uSignal degradation factor should be considered when taking a long distance transmission The output mode

ushould be with low output resistance and strong antidisturbing capacity.

uThe transmission distance for pulse signal is related with the following factors : frequency, output circuit, circuit, transmission cable and transmitting frequency.

Electric related

uThe output cable of encoder and power cable can not be fixed together or putted in same tube. The output cable should also be far from the switchboard to avoid disturbing . The cable should be shielded.

uCareful check should be taken before starting the machine, the product instruction should be matched with the encoder model, wire connection should be correct , wrong connection will damage the internal circuit.

uSignal degradation factor should be considered when taking a long distance transmission. The output mode

should be with low output resistance and strong antidisturbing capacity.

uThe transmission distance for pulse signal is related with the following factors : frequency, output circuit, circuit, transmission cable and transmitting frequency.

Environment related

uThe encoder is a precision apparatus, when use it , it should be far away from vibration source.

uThe encoder is not designed with sealed structure, prevent water or oil etc. splashing on it. Use a protecthood if necessary.

uThe environmental temperature and humidity should be in the operation range.

u Note: performance and service life of encoder will be affected seriously by improper
