Fast Recovery Diode

详情

In electronics, a diode is a type of two-terminal electronic component with a nonlinear current–voltage characteristic. A semiconductor diode, the most common type today, is a crystalline piece of semiconductor material connected to two electrical terminals.[1] A vacuum tube diode (now rarely used except in some high-power technologies) is a vacuum tube with two electrodes: a plate and a cathode.

Semiconductor diodes have nonlinear electrical characteristics, which can be tailored by varying the construction of their P–N junction. These are exploited in special purpose diodes that perform many different functions. For example, diodes are used to regulate voltage (Zener diodes), to protect circuits from high voltage surges (Avalanche diodes), to electronically tune radio and TV receivers (varactor diodes), to generate radio frequency oscillations (tunnel diodes, Gunn diodes, IMPATT diodes), and to produce light (light emitting diodes). Tunnel diodes exhibit negative resistance, which makes them useful in some types of circuits.
(Ultra Fast Recovery Diode)
UFDXI**0H *0A ***0V Trr=**0ns
UFDXI**5H *5A ***0V Trr=**0ns
UFDXI**0H *0A ***0V Trr=*0ns
UFDXI***0H **0A ***0V Trr=*0ns
FDXI**5 *5A **0V Trr=*0ns TO***0
FDXI**0 *0A **0V Trr=*0ns TO***7
FDXI**0 *0A **0V Trr=*0ns TO***7
