The OV***0 CMOS image sensor is a
high-performance image sensor that features a 2.*-megapixel
resolution (***0x***0 pixels) and advanced image processing
capabilities. It is capable of capturing high-quality images and
video even in low-light conditions, thanks to its low-light
sensitivity and advanced pixel technology.
The FOV **0 degree distortionless lens
OV***0 HD CMOS camera module is a type of camera module that uses
an OV***0 CMOS image sensor and a ***-degree field of view lens
with minimal distortion.
The ***-degree distortionless lens is
designed to provide a wide-angle view without any noticeable
distortion, making it ideal for capturing panoramic views,
landscapes, and group shots. The HD CMOS camera module is made from
high-quality optical glass and is coated to reduce glare and
improve image quality.
The FOV ***-degree distortionless lens
OV***0 HD CMOS camera module is a high-performance camera module
that is ideal for a wide range of applications, including security
cameras, drones, video conferencing systems, and
more.
HD CMOS camera module Technical
Parameters
| Model No. | HBVCAM****6HD V4 |
| Model Size | *8mm × *8mm × *7.5mm±0.5MM |
| Temperature (Operation) | **0°C to *0°C |
| Temperature (Stable Image) | 0°C to *0°C |
| Assembly technique | SMT (ROSH) |
| Focus | Fixed |
| Object distance | *0CM-infinity |
| Resolution | **0LW/PH (Center) |
| PCB printing ink | Black |
| interface | USB 2.0 |
| Power supply | USB bus power |
| supply voltage | DC 5V±5% |
| Maximum Power consumption | ***0mW |
| Operating system request |
Win XP/win 7,8 / vista /android 4.0/
mac /Linux with uvc |
| Sensor | OV***0 (1/2.7 ) |
| Seneor Package | CSP,Bare Die |
| Maximum resolution | ***0****0 |
| Sensitivity | *0mV /(lux-sec) |
| Pixel Size | 3μm x 3μm |
| Maximum Image Transfer Rate |
MJPEG **0x**0 *0FPS
/
YUY2 **0x**0 *0FPS MJPEG **0x**0 *0FPS / YUY2 **0x**0 *0FPS MJPEG **2x**8 *0FPS / YUY2 **2x**8 *0FPS MJPEG **0x**0 *0FPS / YUY2 **0x**0 *0FPS MJPEG ***0x**0 *0FPS / MJPEG ***0x***0 *0FPS / |
| S/N Ratio | *9B |
| Max Dynamic Range | *9 |
| Shutter type | Electronic rolling shutter |
| AGC/AEC/Whiter balance | Auto |
| Output Formats | YUY2/MJPEG |
| Microphone | NO |
| Lens Construction | 2G2P |
| F/No | 2.4 |
| EFL | 3.0mm |
| FOV | **0° |
| TV Distortion | <5% |
| Relative Illumination (Sensor) | *0% |
| IR Filter | **0±*0nm |
| Module Package | Anti-electrostatic tray |
| Certifications | FCC/CE/ROSH |
| USB cable | *0CM 1M 2M 3M |
| 1. The parameters of FOV are just for your reference, Different Lens has different FOV 2. The frame rate is related to Light, operating system and so on, the frame rate exist a little error. | |
