high pure graphite block

离岸价格

获取最新报价

4.5 ~ 15 USD / Kilogram

|

2000 Kilogram Minimum Order

国家:

China

型号:

WX-4, WX-5, WX-6, WX-7, WX-8, WX-10, HWX-6

离岸价格:

4.5 ~ 15 USD / Kilogram 获取最新报价

位置:

Baofeng country of Pingdingshan City,China

最小订单价格:

4.5 per Kilogram

最小订单:

2000 Kilogram

包装细节:

wood cases or as customer required

交货时间:

within 7days after received the advance payment

供应能力:

1500 Ton per Month

付款方式:

T/T, L/C, Western Union, Money Gram

现在联系

联系人 Elko

Pingdingshan, Henan

现在联系

产品规格

  • Application: used in Semiconductor Processing, Monoccrystalline Silicon, EDM, Copper Continuous Casting, Metal mo
  • Diameter: Ф840*760;Ф630*640;Ф460*460;Ф560*520;Ф415*410;Ф250*260;510*310*250;340*340*165;1450*650*310;910*310*3
  • Length: 300mm-2100mm
  • Resistance (??.m): 8-10,11-13,8-9
  • Porosity (%): 11-12
  • Compressive Strength: 85-135
  • Brand Name: WX
  • gray:ISO9001:2008 standard
  • Five-star graphite company :Ash:30-50ppm

详情

Fine grain and large size high pure graphite block



Isostatic graphite is a new type of graphite material developed in the ***0s and has a series of excellent properties. For example, isostatic graphite has good heat resistance, and its mechanical strength does not decrease but increases with increasing temperature in inert atmosphere, reaching its highest value at about ***0 ℃. Compared with ordinary graphite, the structure is fine and dense, and the uniformity is good. The coefficient of thermal expansion is very low and has excellent thermal shock resistance. Isotropy; Strong chemical corrosion resistance, good thermal conductivity and electrical conductivity; has excellent machining performance.



Five Star Carbon has the advantages of small resistance coefficient, high temperature resistance, corrosion resistance, oxidation resistance, good thermal shock resistance, low conductivity, thermal expansion coefficient, self lubrication, easy precision machining, etc. It is an ideal graphite anode and grid for inorganic nonmetal crucible boat, heater for single crystal furnace, EDM graphite, sintering mold, tube anode, metal coating, graphite crucible for semiconductor technology, emission tube, thyratron and mercury arc rectifier, etc.



 Five star carbon focus on the different parameters and product performance of isostatic pressing block according to different application fields, the customers can select their required materials.For example, WX - 7, WX - 8 and WX - *0 have the characteristics of high density, high compressive strength, high resistivity, large Shore hardness, large and stable coefficient of thermal expansion, small granularity, low ash content and so on, and are recommended for use in EDM and photovoltaic industries. WX - 6 has the characteristics of high density, high strength, high thermal conductivity, large coefficient of thermal expansion, low particle size and low ash content. It is recommended to be used in metal continuous casting, high temperature casting and metal sintering industries.



Therefore, we can select the most suitable materials for our customers, produce the highest quality products, and at the same time, save the cost to the greatest extent.So that both sides can achieve win-win cooperation and establish a long-term cooperative partnership.


Applications



* Molds, chutes, sleeves, sheathes, linings, etc. in continuous casting systems for making shaped steel, cast iron, copper, aluminum.

* Sintering molds for cemented carbides and diamond tools.

* Sintering molds for electronic components.

* EDM machining graphite block .

* Heaters, heat shields, crucibles, boats in some industrial furnaces (such as furnaces for pulling monocrystalline silicon or optical fibers).

* Bearings and seals in pumps, turbines and motors.

* Heater for mono crystal furnace and Polycrystalline ingot furnace in the Photovoltaic Industry



国家: China
型号: WX-4, WX-5, WX-6, WX-7, WX-8, WX-10, HWX-6
离岸价格: 4.5 ~ 15 / Kilogram 获取最新报价
位置: Baofeng country of Pingdingshan City,China
最小订单价格: 4.5 per Kilogram
最小订单: 2000 Kilogram
包装细节: wood cases or as customer required
交货时间: within 7days after received the advance payment
供应能力: 1500 Ton per Month
付款方式: T/T, L/C, Western Union, Money Gram
產品組 : high pure graphite
