JZC**0 concrete
mixer
JZC**0 concrete mixer is composed by the feeding, mixing,
transmission and water supply institutions, chassis and
electronic control system and other components, is a new
generation of concrete mixing equipment, the mixer with high
quality mixing, reasonable structure, excellent production
efficiency, easy to move, etc. , By the user's praise and
affirmation.
Advantages:
1. Mixing quality is excellent, high production efficiency,
strong stirring performance;
2. Ring gear drive, reliable transmission, the overall light
weight;
3. Low energy consumption, reasonable structure;
4. Stable operation, easy opeation;
5. Brand protection, quality assured.
Parameters
Feed capacity: **0 liters
JZC**0 concrete mixer Pump power: 0.*5 kW
Discharge capacity: **0 liters Water supply accuracy: ≤ 2%
Productivity: ****0m³ / h Mixing cylinder speed: *3 rev / min
Stirring lifting power: *1 kilowatts Aggregate maximum particle
size: *0/*0 mm
To enhance the motor power: 5.5 kilowatts maximum speed: *0kg / h
The detail of products
(1)feeding
system
JZC**0 concrete mixer feeding system has hoisting mechanism,
feeding rack, hopper, feed funnel and other components.
A brief description of the work
The brake motor is driven by the reducer to rotate the drum, and
the wire rope is climbed up along the upper hopper rail by the
pulley tractor. When climbing to a certain height, the two
rollers on the bottom of the hopper enter the horizontal fork of
the upper frame and automatically open the bucket , The material
into the mixing tank through the feed tank.
(2)mixing
syatem
Brief description of mixing
The structure of the stirring cylinder is a double cone-shaped
cylinder, and the high and low blades are welded in the cylinder,
respectively, and the stirring angle is a certain angle with the
stirring axis. With the rotation of the mixing cylinder, the
blade makes the material in the lifting and falling Stirring
back, so stirring strong, stirring effect is better. The stirring
cylinder is supported by four tugs. The rotation of the stirring
cylinder is realized by the large gear of the cylinder driven by
the motor through the transmission device, and the transmission
is reliable.
(3) water supply
system
Start the pump will be able to inject water into the mixing tank,
the time relay in the electronic control system to control the
pump running time to master the water required to stir the
concrete per tank, when the knob to the "time control", the pump
will automatically run by time and
（4）
chassis
JZC**0 concrete mixer with the front wheel, chassis four corners
with legs, you can adjust the level of the mixer should be the
work of the legs to support the stability of the machine.
（5）common
problem
①How the JZC**0 concrete mixer water supply system work?
A: start the pump, you can inject water into the mixing cylinder,
stirring the water required per tank of concrete, the electronic
control system in the time relay control pump running time to
master, when the to the "time control" position, the pump
will Set the time to run and automatically stop. When the
is rotated to the "manual" position, it can be continuously
supplied with water. The JZC**0 also has a separate pipe for the
outside of the mixing tank and the cleaning machine.
②How is the JZC**0 concrete mixer chassis structure work?
A: The chassis is welded. The JZC**0 mixer is equipped with a
front wheel, and the four corners of the chassis are equipped
with adjustable high and low legs. Mixer work, the legs should be
fastened to stabilize the machine. When dragging, the legs should
be stuck in their highest position with a bolt fixed, and should
be turned on the front wheel hanging.
