LoRa transceiver module RFM95W

详情

Descriptions of RF Transceiver Module RFM*5W:

The  RFM*5W transceivers  feature  the  LoRaTM  long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption.

Using Hope RFs patented LoRaTM modulation technique RFM*5W can achieve a sensitivity of over ***8dBm using a low cost crystal and bill of materials. The high sensitivity combined with the integrated **0 dBm power amplifier yields  industry  leading  link  budget  making  it optimal for any application requiring range or robustness. LoRaTM also provides significant advantages in both blocking and selectivity over conventional modulation techniques, solving the traditional design compromise between range, interference immunity and energy consumption.

These devices also support high performance (G)FSK modes for systems including WMBus, IEEE**2.*5.4g. The RFM*5W deliver exceptional phase noise, selectivity, receiver linearity  and  IIP3  for  significantly lower  current consumption than competing devices.

Features of RF Transceiver LoRa Module RFM*5W:

● LoRaTM Modem.

● **8 dB maximum link budget.

● **0 dBm - **0 mW constant RF output vs. V supply.

● **4 dBm high efficiency PA.

● Programmable bit rate up to **0 kbps.

● High sensitivity: down to ***8 dBm.

● Bullet-proof front end: IIP3 = **2.5 dBm.

● Excellent blocking immunity.

● Low RX current of *0.3 mA, **0 nA register retention.

● Fully integrated synthesizer with a resolution of *1 Hz.

● FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.

● Built-in bit synchronizer for clock recovery.

● Preamble detection.

● **7 dB Dynamic Range RSSI.

● Automatic RF Sense and CAD with ultra-fast AFC.

● Packet engine up to **6 bytes with CRC.

● Built-in temperature sensor and low battery indicator.

● Modue Size：*6**6mm

Applications of RF Transceiver Module RFM*5W:

● Automated Meter Reading.

● Home and Building Automation.

● Wireless Alarm and Security Systems.

● Industrial Monitoring and Control

● Long range Irrigation Systems
