paper wrapping machine

详情

   paper wrapping machine

         1.servo motor drive

         2.Tuch_screen display control

         3.Air Tractor

         4.Fully enclosed housing

         5.Two production lines in one machine

         6.Ehth floor of a production line canpacka

Acceptance criterion: take the real production operation when delivery; commodity inspection and testing bureau inspects the product; delivery respecter inspects.

Acceptance standard: pitch control, rotary speed control, the temperature of machinery part can not exceed *0°C within half an hour during the log on state;

Electric appliance wire, driving parts, pneumatic elements, protected enclosure, safe lock of lapping tray

Instruction of this machine: this machine is full-closed lapping avoiding the dust tucking into insulating paper. It adopts the machinery constant expansion force and adopts the apron wheel to draw and has no slide or stall. The whole machine adopts the synchronization serrate belt to drive so that the lay of lapping multi-ply paper does not drift. It also adopts the paper-breaking automatic stop device. The lay of lapping adopts the electric stepless speed transmission to control for assuring the overlap degree.

The take-up adopts moment motor, polished rod pay off, line coil electric fluctuating, decreasing the labor intensity.

Range of applicability: width: 4~*0mm

        Thickness: 1~*5mm

            *0~**0mm2

         Width/thickness: 0.4~*2

Lapping head: imitate the import product, cage type

Two sets of pay off stand in vertical and horizontal direction respectively and match with the rolling alignment and half-hard line device.

Cleaning: four electric nylon brush, range in *0 angle.

  Adopt four-sides cleaning: clean the oil spot, oxic horizon, small burrs, etc of surface of a and b sides of the copper wire in respective.

The range of lay pf lapping: 8~*0mm,  electric digit display, stepless adjustable

       Lay of lapping drift: ±0.4mm

          Expansion force of lapping: machinery automatic constant expansion force adjustment

         Rated speed of lapping head: **0RPM

         The lapping head assure the maxi. operation speed: **0RPM

         Diameter of paper tray: outside diameterΦ**0mm,inside diameterΦ*5mm

         The quantity of paper tray on each lapping head: 4 pieces

   Sheet breaks down: mechanical control

Install the safe protected lock on each lapping tray for avoiding the dropping of paper tray.

The seat material of lapping tray adopts the imported alloy aluminium from America which is characterized as high strength and portability and it is taken out the quench treatment for avoiding the screw slippery tooth.

Bedrail drawing:. It adopts the pneumatic control which is not only nice on appearance but also convenience on operation.

    Control cabinet: display the emergency stop, start, stop, inch, stepless speed changing, display the speed, key starts and closes the general power; stepless speed changing control.

Notes: Price Description

1,       Servo motor drive

2,Touch-screen display control s

3,Air Tractor

4,Fully enclosed housing

5,Two production lines in one machine

6,Each line can pack four
