Pellet Mills With Good Quality and Competitive Price Made In China

China

KMPM

5000 ~ 15000 / Set 获取最新报价

-

5000 per Set

1

-

30 days

600 Set per Month

T/T

Pellet Mill

现在联系

产品规格

Capacity : 500kg-3000kg/h

详情

Hot-Sale And Good Quality Wood Pellet Mills Of KMEC

Why choose our Ring die wood pellet machine?
 1.We have more than 20 years' experience in biomass pelletizing industry, specialize in wood pellet line, poultry feed plants and briquette making machine.
2. We have installed nearly 200 biomass plants all over the world with our advanced technology and best service.


3. We have authoritative experts for designing, testing and installing machines.



4. Our installation and service team have been meticulously trained for any condition.



5. Good inspection of storage. (See following pictures of inspection, pictures speak louder than words.)











  Ring die wood pellet machine Introduction
KMPM520 biomass pellets mills are specially designed for mass industrial production of wood pellets. They are ring die pellet mils, widely used to make pellets from pinewood sawdust, oil palm material such as Empty Fruit Bunch (EFB), mesocarp fibre, etc. Large scale ring die pellet mills can be used for  feedstuff and wood pellet fuel.




Feature Of Ring Die Wood Pellet Machine

♦The biomass pellets mill is equipped the auto-lubricate system
The imperative feeder device is adopted, which making the machine operate smoothly as the material like wood sawdust, corn, wheat, and rice straw is very light, so they are needed to be pushed into pelletizing chamber by force.
The international advanced compensation type flexible coupling is of novel and compact structure, safety, low noise and less trouble.
The driving gear adopts the high precision gear transmission structure. The ring die adopts the hoop fastening method, which increases the speed of discharge compared with the past bolt fastening method.
As per the ring die and roller of the biomass pellets mills, we use the fine machining with the alloyed steel.

Parameter Of Ring Die Wood Pellet Machine


Model Power(kw) Yield(kg/h) Dimension (L*W*H)(mm) Net Weight(kg)
KMPM350 Feeder 0.75 500 2450*1000*2300 1990
Conditioner 5.5
Force Feeder 0.55
Main Motor 55
KMPM420 Feeder 0.75 800-1000 3200*1100*2850 2430
Conditioner 5.5
Force Feeder 0.55
Main Motor  90
KMPM520 Feeder 0.75 1500-2000 3300*1250*2550 3500
Conditioner 5.5
Force Feeder 0.55
Main Motor 75*2
KMPM650 Feeder 3 (Frequency Controllable) 2500-3000 3900*1500*2800 4900
Conditioner 7.5
Force Feeder 1.5
Main Motor 110*2


Raw Material And Final Pellet Of Ring Die Wood Pellet Machine







Livestock and poultry's waste,tea waste,tea waste,forestry wastes,forestry wastes,wood chips and many other organic waste resources.



Soft wood and hard wood chips, saw dust



Agriculture straw & stalk pellets.



 Application Of Ring Die Wood Pellet Machine







This type of machine can apply for the castoff of agriculture and forestry also for the rubbish of city life. Both win the society benefit and economy. And the Pellet fuel made by pellet mill is mainly made of sawdust, shavings, fines and rightover after processing trees for lumber or other wood products. At a wood pellet plant, raw material need to be well prepared before pelletizing. After dried, compressed, and formed into small eraser-sized bits, the wood pellets get from wood pellet plant are clean, pleasant smelling and smooth to touch.
