Introduction:
Choose the most suitable powder coating line according to your actual condition.
The followings are 5 common powder coating line, you can also contact me to help you to design the most suitable plan.

Mode 1: Manual powder coating:
Pretreatment, manual spraying, manual transfer to high temperature curing oven,then powder coating finish.
Advantages:
Less investment; apply to various workpieces spraying as long as the size of curing oven is designed reasonable; convenient maintenance; low cost; Easy to operate; less occupied area. Suitable for large and small batch production
Disadvantages: High demand for labor and Production capacity is slightly lower

Mode 2: Full automatic powder coating line:
The workpiece hanging in automatic running chain: Loading, spraying pretreatment (not including pickling), drying in low temperature drying tunnel, automatic spraying, manual repair painting, high temperature oven curing, cooling the workpiece, unloading, powder coating finish.

Advantages: When spraying large quantities of the same workpiece, it will reduce the labor costs and energy consumption.
Disadvantages: Not suitable for small batch production.Only apply to workpieces with the standard shape in a certain range; Maintaining of spraying pretreatment requires high technical operation, complex maintenance and high maintenance costs, large area occupied. Applicable to long-term batch spraying of fixed workpiece.

Mode 3: semi-automatic powder coating line:
Pretreatment (not in the coating line), loading, manual spraying, high temperature oven curing, cooling, unloading - coating finish.
The workpiece walking automatically with the spray chain, when passing through the coating booth with two spraying stations,  2 workers each holding a spray gun complete the spraying work; the workpieces after coating come out from coating booth, entering the constant temperature curing oven, then complete curing work.

Advantages: When spraying large quantities of the same workpiece, it has a considerable advantage of daily output. Much less investment and maintenance cost and difficulty than full automatic powder coating line. Almost the same daily output capacity with full automatic line.
Disadvantages: does not apply to irregular workpieces with small batch spraying, small batch will still cause high energy consumption and spraying cost.

Mode 4: A common used automatic powder coating line:
Pretreatment is not included in coating line. Workpieces after pretreatment: loading, automatic spray, manual repair painting, high temperature curing in curing tunnel, coating finished.

Advantages: "automatic powder spraying" bear the most of the spraying work,reduces the operator labor intensity of spraying; The existence of automatic gun accelerates the spraying speed. So the running speed can be greatly improved, to obtain higher yield; eventually reduce the single spraying cost;
Disadvantages: does not apply to irregular workpieces with small batch spraying, small batch will still cause high energy consumption and spraying cost.

Mode 5: the small circulation spraying chain and curing oven with 2 sides openning: Building a small cycles spraying chain with 2 working station manual coating booth, workpiece hanging on the chain running automatically, passing through the coating booth in a constant speed, 2 workers each holding a manual spray gun spraying on the workpieces; then manually transferred the coated workpieces to curing oven; This spraying method, the spray ability accessible to" semi-automatic powder coating  line ", but lower investment and smaller occupied area.

Advantages: high spraying efficiency, spraying quality is easier to control than mode 1; Daily output get close to mode 3, semi-automatic coating line if workers are matched well.
Disadvantages: does not apply to irregular workpieces with small batch spraying, small batch will still cause high energy consumption and spraying cost.
