The maximum
efficiency of the inverter is up to 97.6%.
Single MPPT
Transfomer-less
design
Wide range of MPPT
voltage
The units have
built-in leakage current monitoring devices.
Units use
thin-film capacitors ensuring better product performance.
IP65 protection
class
Optional DC switch
indoor and outdoor
installation option
Multilingual LCD
display for the user to select
Hanging design
makes installation easy.
RS485 integrated
interface and the Bluetooth communication module makes the
units convenient for monitoring
| Sunmax 1500 | Sunmax 2500 | Sunmax 3600 | Sunmax 4600 | |
| DC Input | ||||
| Max. DC power | 1750W | 2890W | 4150W | 4770W |
| Max. DC voltage | 450V | 500V | 550V | 550V |
| System start-up voltage | 110V | 110V | 110V | 110V |
| Full load voltage range MPPT | 200V-360V | 235V-400V | 230V-440V | 280V-440V |
| Operating voltage range | 110V-430V | 110V-480V | 110V-530V | 110V-530V |
| Max. DC current | 9A | 13A | 18A | 18A |
| DC voltage ripple | < 5.0% | |||
| No. of Mpp trackers | 1 | |||
| NO. of DC connector | 1 | 2 | 3 | 3 |
| AC output | ||||
| AC rated output power | 1500W | 2500W | 3600W | 4600W |
| Max. AC power | 1650W | 2750W | 3600W | 4600W |
| Max.AC current | 9A | 16A | 16A | 23A |
| THD of AC current | < 3.0% | |||
| Grid voltage range | 220V/230V/240V | |||
| Grid frequency | 50Hz | |||
| No. of feed-in phases | Single-phase | |||
| Power factor | 0.99 | |||
| Efficiency | ||||
| Max. efficiency | 96.5% | 96.6% | 97.5% | 97.6% |
| European efficiency | 95.0% | 96.6% | 97.5% | 97.6% |
| MPPT efficiency | 99.5% | |||
| Protection | ||||
| Reverse polarity protection | Yes | |||
| DC switch | Optional | |||
| Short-circuit Protection | Yes | |||
| Ground fault monitoring | Yes | |||
| Grid monitoring | Yes | |||
| Over-voltage protection | Yes | |||
| Over-current protection | Yes | |||
| Active anti-islanding | Yes | |||
| Ground fault current detection | Yes | |||
| General Data | ||||
| Dimensions | 360/500/155 | 360/500/155 | 360/500/155 | 360/500/194 |
| Weight | 14kg | 14kg | 14kg | 18.4kg |
| Ambient temperature | - 25°C - +60°C | |||
| Altitude | < 3000M | |||
| Noise | < 30 dB | |||
| Power consumption night | < 0.2W | |||
| Power consumption standby | 4W | 5W | 5W | 6W |
| Topological structure | Transformer-less | |||
| Cooling | free convection | |||
| Protection class | IP65 | |||
| DC connections | MC4 | |||
| AC connections | Plug connector | |||
| Display | Yes | |||
| RS485/WIFI | Standard configuration/Optional | |||
| 国家: | China |
| 型号: | Sunmax 1500/2500/3600/4600 |
| 离岸价格: | 获取最新报价 |
| 位置: | - |
| 最小订单价格: | - |
| 最小订单: | 1 Unit |
| 包装细节: | On Request |
| 交货时间: | Depend On Order |
| 供应能力: | 1000 Unit per Week |
| 付款方式: | T/T, Western Union |
| 產品組 : | - |
