EARFLAP
Everyone Can Use Wrapper Now!
With European technology& Chinese supply chain efficiency and
manufacturing cost
We make our wrappers with a philosophy.
Focus on the machine itself, stable quality is always our No. 1
competence.
Focus on the user ease of use and hassle-free operation is our
commitment to you.
Focus on ROI we ensure our machines are tools, not burdens.
Low turntable wrapper -
featuring innovative technology with a goods incline angle of less
than 3° smooth, stable, and durable loading.
Universal 1 6 8 0 mm, 3 0 0 mm thick low round turntable, Maximum
loading capacity of 1 0 0 0 kg and height of ***0mm.
Four types of carriage with pre-stretch ratio from 1 0 0 % to 4 0 0
%.
Six wrapping modes and six optional accessories.
One-touch operation with an LCD touchscreen.
Spanish red turntable paired with elegant silver columns, a simple
yet luxurious design.
Technical Data
|
Low Turntable Wrapper Model EF-CRT-L 1 6 8 2 2 -PC |
Low Turntable Wrapper (Large Column) Model EF-CRT-L****7L-PC |
|
| Machine Features | ||
| Size （L×W×H) | 2 5 0 0 ×1 6 8 0 × 2 2 3 0 mm | ***0×***0×***0mm |
| Column Height | 2 2 0 0 mm | ***0mm |
| Option: 2 7 0 0 mm/ 3 2 0 0 mm | Option: ***0mm/***0mm | |
| Turntable Diameter | 1 6 8 0 mm | |
| Weight | 5 0 0 - 6 0 0 kg | |
| Operator Panel | LCD Touch Screen | |
| Electricity Features | ||
| Power Supply | 1 P 2 2 0 V- 2 3 0 V/ 1 1 0 V 5 0 / 6 0 HZ | |
| Installed Power | 1 . 2 5 KW | |
| Wrapping Features | ||
| Wrapping Speed | 9 0 s / Pcs | 1 0 0 s / Pcs |
| Turntable Speed | 0 *1 0 rpm | |
| Carriage Lifting Speed | 0 - 5 . 4 m/min | |
| Load Height | 2 0 0 0 mm or Pillar Height minus 4 0 0 mm | |
| Load Weight | 1 0 0 0 kg | |
| Wrapping Model | 6 Wrapping Models | |
| Film Pre-stretch | Damping Carriage : 1 2 0 %/ 1 5 0 % | |
| Pre-stretch Carriage : 1 0 0 %- 1 5 0 %- 2 0 0 %- 2 5 0 % / 1 0 0 % - 4 0 0 % Adjustable | ||
| Film Tensing | Adjustable | |
| Height Control | Photoelectric automatic | |
| Film Carriage | ||
| Carriage Types | Damping Carriage | |
| Pre-stretch Carriage | ||
| Filming Method | By Manual | |
| Roll Features | ||
| Roll Size (H×diameter) | 5 0 0 mm× 2 5 0 mm | 5 0 0 mm / 7 5 0 mm× 2 5 0mm |
| Roll Diameter | 5 0 / 7 6 mm | |
| Roll Weight | 2 0 kg | |
| 6 Wrapping Models | ||
|
Cross-wrap Single-wrap Cross-plus Manual-wrap Positioning-wrap Cross-plus |
||
| 8 Optional & Accessories | ||
|
Loading Ramp Top Presser Automatic Film Cutter Roping System Net/Bubble Flim Weighing system Doors & Windows Wrapping System(Use with Top Presser, max. loading weight is ***0kg) |
||
