Solar Adaptor for Inverters Solar Adaptor for Inverters Solar Adaptor for Inverters
Next

Solar Adaptor for Inverters

离岸价格

获取最新报价

125 ~ 145 / Unit

|

1 Piece Minimum Order

国家:

India

型号:

Solar Adaptor- 12/24-30A

离岸价格:

125 ~ 145 / Unit 获取最新报价

位置:

-

最小订单价格:

125 per Unit

最小订单:

1 Piece

包装细节:

Individual piece in single carton box

交货时间:

30 days lead time

供应能力:

500 Piece per Month

付款方式:

PayPal, Money Gram, Western Union, D/A, L/C, T/T

现在联系
免费会员

联系人 Prasanna

Jc Road, Bangalore, Karnataka

现在联系

产品规格

  • Input Voc:Min 35 v - Max 75 V for 24 v system
  • PV Charger Effeciency:>95%
  • Input Voc:Min 22 v - Max 44V for 12 v system
  • Weight:6.5 Kgs
  • LCD Display:Pv Input Kwhr and Load output Kwhr
  • LCD Display:PV Amps, Battery Voltage

详情

Solar adapter for inverters is designed to convert any inverter or home UPS to the functionality of a regular solar PCU. The product when connected to a standard inverter ensures that the inverter is turned On and Off based on Pv generation and battery logic set at the time of installation. It also disconnets inverter from battery in OFF mode which avoids drainage of batterys in stand by mode.. Another unique functionality of the product is its ability to mute grid charging of the inverter to give solar preference.

The product is user friendly and has all the latest features along with programmable settings of various functional parameters to optimize for the for best performance. and utilization of solar Pv.

By using our product you are assured about getting the best efficiency in Pv conversion to load and trouble free performance due to its rugged industrial design and construction.

Our Services : We offer technology transfer by the way of technical collabration. All information pertaning to product hard ware design, Pcb gerber, mechanical design of enclosure, transformer and magnetic component design will be provided.Microcontroller loaded with embedded software needs to procured from us directly.


Using our technology manufacturer of the product can save on product cost and international freight. One can independtly provide service back to their customers and address local site issues and market requirments. We also assist in material sourcing from right destinations at competative cost.

Key Features:

  • Battery is disconnected from inverterin its OFF mode and reconnected when inverter needs to switch On,ensures extended backup in stand alone applications.
  • Grid Charger of inverter can be muted or enabled based on Pv generation and usage of power.
  • Solar / AC charging preference option: Set points to cut off grid charging
  • Multi Function LCD: displays key parameters about Battery voltage, Load %, Pv generation, Time and date, Inverter mode/ mains mode, error Batt low, Overload, short circuit and log of energy received and ulifesed Kw hr.
  • MPPT charger for solar: Maximum power point tracking solar charger with Perturb and observe algorithm with current display and 3 stage charging for optimal battery charging and extended battery life.
  • Auto Timer: Inverter can be programmed to Turn ON and OFF at a preset time with an in built RTC, this feature is used to optimize solar energy backup without any need for ACcharging. Loads will be transferred to GRID after the timer off time and grid charging will not be done.
  • Over load Set Function:The unit has a OL monitoring function in mains made which prevents the transfer of ac load to Invertrer, if heavy load is connected during mains mode usage. This prevents the damage of external inverter due to heavy load.
  • Multiple auto discharge mode selection:Timer based/ Battery voltage logic based. This features provides the user flexibility to optimize the performance of Pv system based on customer requirements and site conditions of use



国家: India
型号: Solar Adaptor- 12/24-30A
离岸价格: 125 ~ 145 / Unit 获取最新报价
位置: -
最小订单价格: 125 per Unit
最小订单: 1 Piece
包装细节: Individual piece in single carton box
交货时间: 30 days lead time
供应能力: 500 Piece per Month
付款方式: PayPal, Money Gram, Western Union, D/A, L/C, T/T
產品組 : Solar Prioritiser
