Solar Portable Power system

详情

I. Brief Introduction Portable Solar Power Supplier characterize with many function, small size, light weight, high power output, high transfer efficiency, alternative charging & being charged. There are solar panel, storage battery, controller, and inverter and necessary accessories in the “luggage” box in one. It is with AC & DC output, and the AC output is both suitable for your local **0V/**0V socket of electric appliances, the DC output is with variable voltage for your match and will be showed on the meter indicator. The AC’s & output are all controlled by one-key indication light, as well as the same for DC’s, and the whole involved circuits are all with protection function, and thus ensure no disadvantage happen on the box if no discharge. II. Structure The power supply outside box adopts high quality aluminum alloy material and inside it use high conversion efficiency poly-crystalline silicon panel. Below the solar panel, the battery is installed according to special bracket to fasten battery to the bottom of the box. .The most outside is the controlling panel, including the following parts: 1. Main switch: When working, please make sure the switch is in “on” status. 2. Display battery voltage: Indicate the voltage you can use maximum. 3．Output 5V, 9V, *2V:Suplly multi-AC output Voltage for your choice. 4．Display output: Show the Voltage you are using. 5．DC output socket: DC output for cell phone or suitable ones & one more for airplane special socket. 6. AC **0V/**0V output socket: omnipotence socket directly connect to AC**0 or **0V. 7. Input. Output indicator: Show by LED light. 8. AC switch: in red color, control the output of AC. 9. DC main switch: in green color (in the middle), control the output of DC and the working of DC switch (on the right). *0. DC switch: in green color (on the right), control the output of DC.
