Auto control system Multi-function Rope-Making Machine

离岸价格

获取最新报价

( Negotiable )

|

1 Set Minimum Order

国家:

China

型号:

ACS254

离岸价格:

( Negotiable ) 获取最新报价

位置:

china

最小订单价格:

-

最小订单:

1 Set

包装细节:

wood packaging

交货时间:

30

供应能力:

999 Set per Month

付款方式:

T/T

现在联系
免费会员

联系人 Mr. yong

AOJIANG, WENZHOU, Other

现在联系

产品规格

  • Auto control system :ACS254

详情

Introduce:
    The auto control system multi-function rope-making machine is the new ring twister designed for the porduction of multithreaded twisted yarns using natural and synthetic fibers.
    This machine is made to twist continuous filament yarns, monofilaments, strings for chemical filament, textured yarns, glass fiber, fishing net, twine, wool, fabrc cord, cotton yarn, carpet, plied yarns of cotton, wool or chemical fiber and blends into cotton thread, knitting yarn and fine knitting wool.

The main characteristics:
A. integrated style construction
B. travellers speed up to *0 mt/sec
C. automatic ring lubrifcation with cooling system
D. individual AC motor plus inverter each spindle
E. individual start-stop

Machine equipped with PLC showing and setting:
A. twist/mt individual position by position
B. tindividual feeding speed
C. individual spindle speed
D. selection of the meter content
E. preselection of the height of the bobbins and shape of the bobbin
F. max weight of take-up to *7 kg

Technical parameter:

Tyep ACS**4A/*2 ACS**4B/*2
No. of Spindles >*2 spindles >*2 spindles
Spindle Gauge **0mm **0mm
Capacity of finished product Package **4×**2mm **4×**2mm
Main motor Power 2.**3kw/0.*7×*2sets 2.**3kw/0.*7×*2sets
Draw-bar power 1.1kw 1.1kw
Type of speed regulation Frequency changer circuit Frequency changer circuit
servo link power **0w **0w
spindle speed ********0r/min ********0r/min
scope twist degree ******0T/M ******0T/M
Type of test twist degree Auto control system(PLC) Auto control system(PLC)
system version ACS*2.0.1 Joint control ACS*2.0.1 Joint control
Operation interface 7`` touch screen HMI 7`` touch screen HMI
Dimension of master **0×**0×***0mm **0×**0×***0mm

国家: China
型号: ACS254
离岸价格: ( Negotiable ) 获取最新报价
位置: china
最小订单价格: -
最小订单: 1 Set
包装细节: wood packaging
交货时间: 30
供应能力: 999 Set per Month
付款方式: T/T
產品組 : rope making machine
