The CO2 Engineered tanks are designed for long-term storage of
liquefied carbon dioxide. Engineered tanks are available in
vertical or horizontal arrangement with a conventional PUR
insulating material. The sealed cladding is made from aluminium
which protects the insulation against mechanical damage and any
moisture penetrating into the insulation. The CO2 engineered tanks
are tailor made according to customer requirements.
The tank capacities range between *0 tons and **0 tons with
maximum allowable working pressure up to *4 bars. Engineered
tanks can be supplied with ambient type of vaporizers, pipelines
and other cryogenic components for a complete installation. The
conventionally insulated vessels are equipped with safety valves,
heaters, load-cell, weighing systems and refrigeration units,
condensing the boil off gas originated from heat accumulation.
The tanks are equipped with dual relief valves to prevent the
possibility of excess pressure risk. Although CO2 Engineered
Tanks are based on a standard design, they can be customized as
per specific application and requirements. The tanks are designed
according to Directive *7/*3/EC, using the standards AD ***0M and
EN ****8. Engineered tanks according to ASME are also provided.
