Garnet 70

详情

NEW ERA IN SERIES OF *0MM WIDTH

Todays city culture and structural technologies are shaped at totally new dimensions. Cities are full of differentiating silhouettes caused by this change. New living areas make aesthetics, isolation, comfort, and efficiency principles to come forward. Following closely this change, we fulfill the need of the differentiating construction technologies with a new series. Garnet Series which interpret *0 mm series with a different aesthetics and isolation perspective is the new choice of the modern structures.

ABOVE-STANDARD SOLUTIONS WITH *0 MM SERIES

Garnet *0 series, which was designed to bring new dimension to the quality and aesthetical understanding of the window standard, increases the comfort in your living areas with the excellent heat and sound insulation. Garnet, whose all profiles have got *0 mm width and 5 chambered design, is the new choice of the architecture. Garnet fulfils the expectations of the new trends with its *1 different color options and starts a new era of windows providing excellent heat and sound insulation in the modern structures.

System

• Garnet *0 system, which provides esthetical integrity thanks to the Oval Drained Sash profile, has two different drained sash profiles options. Oval drained sash profile has the same ovality with the frame; and another drained sash profile is with sharper edges, these are also offered with Garnet *0 system, depending on the customers demand.
• All main profiles of Garnet *0 series have a width of *0 mm.
• While the system has 4 different types of oval shaped glazing beads which increase the interior width, it also offers 4 different decorative glazing bead profile alternatives.
• It can solve all the architectural details thanks to its detailed and auxiliary profiles designed compatible with its main profiles.
• Glass application until *0 mm can be done thanks to the systems glazing bead profiles.
• Garnet *0 series provides you options to meet decorative expectations and add value to your house with its *1 different laminated color application.

Wind Load Resistance

• Garnet *0 systems were designed according to the safety of 3.**0 Pa (**5 km/h) wind load resistance and the strength of **0 Pa (**0 km/h) water impermeability and has successfully passed these tests.
• While developing Garnet *0 system, the maximum wind load values to which the buildings can be exposed were taken into the consideration; the structure of the reinforcement steel and their locations inside the profiles were designed in the most effective way.
• System, whose detailed and grillage profiles provide solutions to meet the architectural needs, easily ensures the closure of the wide openings and necessary resistance values.

Water and Air Impermeability

• Garnet *0 series provides high resistance to water even at high wind loads, thanks to its water drainage channels and sets designed to discharge the rainwater faster and in an easier way.
• The system did not leak any water inside and proved its high quality under tests carried out with **0 Pa (**0 km/h) wind load and 4 liters of rainwater per minute.

Heat Insulation

• The profile designs of the Garnet Series were made as for the thermal conductivity coefficient values to be at minimum levels.
• Profile widths, chamber numbers and chamber widths of the system were created to keep the heat and sound insulation at the maximum levels.
• All profiles of Garnet *0 system have a structure of 5 chambers and since the chamber widths are large, low level thermal conductivity coefficient values are provided.
• Compatible with TS EN ISO ******2 standards, Ug : 0,7 W/m2K, Uw : 1,*5 W/m2K and Uf : 1,2 W/m2K values were accomplished with the windows system which has a size of 1,*3 m x 1,*3 m.

Sound Insulation

• One of the most important criteria in window systems is the sound insulation. High sound levels about *0dB in the areas close to airports, railways or crowded highways are decreased to values under *0 dB at which a child can sleep easily.
• Sound insulation up to *0 dB value can be provided with Garnet *0 series. Therefore, it is possible to create a sound environment at a high quality life level even at the loudest places.
