| Model designation | SFD30 | UNITS |
| Power Type | diesel | |
| Operation Type | Driver seated | |
| Load Capacity | 3000 | Q(kg) |
| Load Barycenter Distance | 500 | C(mm) |
| Axle Center to Fork Face | 484 | X(mm) |
| Wheel Base | 1700 | Y(mm) |
| Weight | ||
| Service Weight | 4260 | kg |
| Axle Weight With Rated Load Front/Rear | 6460/800 | kg |
| Axle Weight Without Load Front/Rear | 1700/2580 | kg |
| Wheels and tyres | ||
| Tyres:SE-Super elastic PN-Pneumatic | PN | |
| Front Tyres Size | 28 x 9-15-14PR | |
| Rear Tyres Size | 6.50-10-10PR | |
| Front Track Width | 1000 | b10(mm) |
| Rear Track Width | 970 | b11(mm) |
| Dimensions | ||
| Mast Lift,Forward/Backward | 6°/12° | α/β |
| Height of Mast,Lowered | 2080 | h1(mm) |
| Free Lift | 145 | h2(mm) |
| Lift Height | 3000 | h3(mm) |
| Height of Mast, Extened | 4273 | h4(mm) |
| Overhead Guard Height | 2108 | h6(mm) |
| Seat Height | 1070 | h7(mm) |
| Drawbar Height | 300 | h10(mm) |
| Overall Length | 3780 | L1(mm) |
| Length to Face of Forks | 2710 | L2(mm) |
| Overall Width | 1225 | b1(mm) |
| Fork Arms Dimensions | 45/125/1070 | s/e/L(mm) |
| Fork Carriage Width | 1100 | b3(mm) |
| Ground Clearance Below Mast With Load | 135 | m1(mm) |
| Ground Clearance Centre of Wheelbase With Load | 140 | m2(mm) |
| Working Aisle Width With Pallet 1000×1200 1200 Across Forks | 4144 | Ast(mm) |
| Working Aisle Width With Pallet 800×1200 1200 Along Forks | 4344 | |
| Turning Radius | 2460 | Wa(mm) |
| Turning Point Minimum Distance From The Truck Center Line | 810 | b13(mm) |
| Performance | ||
| Travel Speed With/Without Load | 20/20.5 | km/h |
| Lifting Speed With/Without Load | 480/540 | mm/s |
| Lowering Speed With/Without Load | 440/455 | mm/s |
| Drawbar Pull Tractive Effort (At2Km/H) With/Without Load | 16.2/14 | KN |
| Gradebility (At2Km/H) With/Without Load | 20 | % |
| Service Brake | Mechanical/hydraulic | |
| Engine | ||
| Engine Manufacturer/Engine Type | WEICHAI WP3.2 | |
| Emission Standard | CHINA STAGE III | |
| Engine Power in compliance with ISO 1585 | 36.8 | kw |
| Rated Number of Revolutions | 2500 | /min |
| Cylinder Number/Displacement | 4/3170 | cm³ |
| Others | ||
| Drive Control Type | Mechanical/Hydraulic torque converter | |
| Noise at Operator's Ear | dB(A) |

(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
