1. Brief Indtroduction (It's only for your reference.)



    Capacity: 141.26 ton/ year, 300g/pc

    Diameter: 7.5cm

    Height: 7.5cm

    Quantity: 470,866pcs.



2. Workers (It is only for your reference.)



    Total workers: 8

   1 worker for wick waxing machine

   1 worker for automatic wick cutting & wick sustainer clamping assembly

   1 worker for instant melting box

   5 workers for semi-automatic filling assembly line



3. Flow charts



    3.1 Making cotton waxing through wick waxing machine.

    3.2 Making cotton which has be made waxing cut and make wick sustainer  clamp through automatic wick cutting & wick sustainer clamping assembly.

    3.3 Making Montan Wax melt through instant melting box.

    3.4 Put mould on the band carrier, and put melting wax into the filling assembly line, then to the first filling part, starting the filling process, when reaching the certain amount, filling process stops, after that, put the wickes (include cotton and wick sustainer) into the moulds, then the band carrier goes again.

    3.5 After cooling, make candles out of the moulds, and put them into the cartoons.



4.  Finished Product Candles





Packing details for finished candles: 72pcs/cartoon (24pcs/layer*3layers), cartoon size: 47*32*25cm.



5. Machine List



Wick Waxing Machine







Automatic Wick Cutting & Wick Sustainer Clamping Assembly
