Customization Solar Panel Production Line

详情

1. Full automatic laminator
USE: As the equipment of manufacturing solar module limited to laminate glass, EVA (Ethylene Vinyl Acetate Sheet), solar cell and back sheet
Dimension: ****0mm x ***0mm x ***0mm
Must attention the size of laminator, make sure the entry of the building is enough
Laminating area:***0mm x ***0mm.  Laminating height: *5mm
Total power consumption: *5 KW (AC**0V, *0 Hz, or according to customer's nee)
Air source: 0.6 - 1.0 MPa.
Operating mode: Manual / Automatic.
Control system :  PLC ( Delta). HIM system: Touch screen (Delta)
Heating mode: Oil Heating (SD**0 hea t-conducting oil, capacity: **0 L, flow pressure:0.3 Mpa.), inculde: main heating and adjustable heating.
Temperature control: PID intelligent temperature contol system.
Temperature uniformity in working area: ≤ ±1.5 ºC
Temperature control accuracy:≤± 1 ºC.
Temperature control range: *0ºC - **0 ºC
Pumping rate:  *0 L/s .Laminating time: 2 - 4 mins (Excluding solidification time)
Heating rate: **5ºC at room temperature with *0 to *0 minutes.
Vacuum rate: **0 L / S, the limit vacuum *0 ~ *0 Pa, vacuum Time: *0 seconds
Silicone sheet size: ***0mm * ***0mm, 5 mm thickness. It will be changed after ***0 times.
Lid opening: Straight from the hydraulic, the biggest opening height: **0 mm
Total weight: *5.8 T
Production capacity: Conventional **0 Wp (***0* **8)  module, 3 pcs at the same time .
Production Capacity: **0 WP * 3 pieces/ time*3 time/h * 8hours * **0 days= 6.*8 MWp/ year.
Warranty period: 1 year.   (Exclusive easily damaged parts).

2. Solar cell tester
The solar cell tester machine to sort solar cells according to their electrical performance, tested under simulated sunlight.
Testing area: **0X**0mm
Dimension:***0x**0x***0mm
Illumination uniformity: ±3%
Test period: < 3 second for each cell.
Working period: *4 hour
Measure the required electrical properties.
