Brief Introduction of SLG Continuous Modifying
Machine:
Continuous Modifying Machine is used for dispersing powder,
modifying surface and filming. The mineral powder surface
modifying, widely used in the fields of non-metal stuffing or
pigment like plastic, rubber, adhesive, macromolecule materials,
high polymer composite, functional materials and dope industries.
It can not only improve the compatibility of both non-organic
mineral stuff and organic high polymer, enhance binding force of
interfaces, raise the mechanical strength and comprehensive
ability, but also increase the stuffing ability of powder, save
product cost and add special physical and chemical property to the
product to some extent.
Application of SLG Continuous Modifying
Machine:
SLG Continuous Modifying Machine is the machine is applicable to
modifying various materials. It can reach excellent surface
modifications for such materials as:
>heavy / light calcium carbonate
> kaoline, talcum
> wollastonite, mica, white carbon black, zinc oxide
> Alumina, silicon powder, graphite
> Magnesium-hydroxide bariumcar
> illite claystone and pyrophylite, hexagonite and etc.
Features of SLG Continuous Modifying Machine:
1. Continuous operation, large capacity, suitable for
industrialization production in various scales.
2. High use and less consumption of modifying agent, high covering
and active index of power, energy saving.
3. Both modifying and dispersion function, suitable for any fine
materials, special active effect for material with small proportion
and big cubage weight like white carbon, mica powder and talcum
powder.
4. Powder and agent mixing and running in high speed and vortex,
high modifying efficiency, with little change of granulate
shape.
5. Running at vacuum, air tight, no dust leakage, no pollution,
good operation condition, low labor intensity.
6. Operating in heat and cold conditions, no additional heating or
cooling system required, easy operation
7. Independent fluid and non-fluid agent adding system for
continuous, stable and even operation.
Model and technical parameter of SLG Continuous Modifying
Machine:
| Type |
SLG-3/300 |
SLG-3/600 |
| Main unit power (KW) |
18.5KW x 3 |
37KW x 3 |
| Blower power (KW) |
5.5KW |
15KW |
| Main shaft rotating speed (RPM) |
4500 |
2700 |
| Output capacity (kg/h) |
500-1500 |
2000-4000 |
| Size (MM) |
5250X1800X5600 |
7218x3680x6450 |
Remarks: A) The above listed capacity is a normal production
capacity; the practical capacity is subject to the area, the
hardness and character of raw materials.
B) Product capacity can be adjusted according to the density
of raw materials.
