DPH250E Automatic Alu-PVC blister packing machine

详情

Introduction:
PVC unreeling material automatically, positive pressure intermittence working. Easily change mold, exact leading and easy adjustment. Frequency controlling feeder (Optional choose is high speed disk feeder).The whole machine is controlled by PLC, FREQUENCY ADJUSTABLE, TOUCH SCREEN OPERATION. Consecutive roller sealing, lines touching let the net-wet clearly. Easy change letter embossing system. The embossing and cutting part use 4 guiding post keep the machine running stale and high efficiency in the high speed station. Waste material collector is good for environment. The machine can be fission transported. It can pack various tablets, capsules, pills and special shaped tablets.

Optional function:
Image monitoring and reject, fill inert gases etc.

Usage:
It applies to capsule, white pill, sugar-coat pill, micelle, special-pill, chocolate, and chewing gum and so on.

Functions and features:
1 With small volume, compact structure, high efficiency.
2 Plate -type pressure-blow molding, roller-type sealing, beautiful production.
3 The machine can be used with general feeder, the disc feeder and special feeder.
4 None-waste border cutting, save materials, move smoothly, easy operation.
5 Have function of printing lot number and make broken line.
6 Easy to change mold.
7 All of PLC automation control, frequency stepless speed regulation, adjust a widely- range, with a little noise.
8 Main parts are imported to ensure the movement smoothly. Closed structure design, the machine adopts stainless steel that according to GMP standard.

Main Specification：
