B200 model is not supported by the inner ring and bearing
wedge-type one-way clutch, must comply with the bearing
installation when used to withstand axial and radial loads, users
also need Tigong grease supply and external
seal. Outer
wall with machine mounted with keyway shaft mounted directly in the
clutch, the clutch for the installation of the shaft after grinding
needs hardening treatment to HRC58 ~ 62, the shaft taper should not
exceed 0.01mm per 50mm, apply to the limit speed: 1000 ~ 2400r /
min nominal torque of 60 ~ 1250N.m. Commonly
used in packaging machinery, metallurgical machinery, mining
machinery, and petroleum machinery, chemical machinery, cement
machinery, power plants and other mechanical drive.
