CONSTRUCTION
These type of resistors use sheets of Nichrome or Fecral or
Stainless
Steel as resistive material. These sheets are punched to
required
Ohmic values and then assembled on tie rod with ceramic support
and insulation as module. Such multiple modules are assembled
in
an enclosure to achieve required power.
APPLICATIONS
Loading Resistors
Dynamic Braking Resistor
Starting Resistors
Neutral Grounding Resistor
Technical
Specifications:
1. Power Rating: 7.****0 KW
2. Resistance Tolerance: +/- *0%
3. Di-electric Voltage: ***0 VAC
4. Insulation Resistance: > *0M Ohm
5. Short Term Over Load : *0 x wattage rating for *0 sec.
6. Temperature Rise: **5 Deg. C + Ambient
7. Safe Operating Temperature **0 Deg. C
Material
Specifications:
1. Enclosure options 2mm, 1.6mm and 1.2mm
2. Powder coated or Galvanized Sheet enclosure.
3. Resistive material Fecral, Nichrome or Stainless Steel.
4. Thermal cutoff **0°C (OPTIONAL)
5. Power Connection Copper/Aluminium Bus Bar or
connector.
6. Protection class available as per requirement.
7. Dimensional Tolerance +/- *0mm.
8. Custom Design Available.
