离岸价格
获取最新报价1 ~ 20 / Acre ( Negotiable )
|Minimum Order
位置:
-
最小订单价格:
最小订单:
50 Unit
包装细节:
individual paper box, master carton
交货时间:
10-30 days
供应能力:
10000 Unit per Month
付款方式:
T/T
联系人 Donna
Zhuhai, Guangdong
| Features | |||||||||
| ● Constant Current output, 50/60Hz | ● Typical lifetime ≥ 50000 hours | ||||||||
| ● Plastic/Aluminum case with cable，Class I. | ● 100% full load bur-in test | ||||||||
| ● Built-in EMI filter with tiny ripple,flicker-free | ● Protection: Short circuit/Over current/Over voltage/Over load | ||||||||
| ● High performace and reliability | ● 3 years warranty | ||||||||
| Model | Output power | Input voltage | Out voltage | Output current | Effi | PF | Warranty | Material /IP | Size(mm) | Weight |
| NC-4160-LC1 | 4W | 200-265V | 15-24Vdc | 160mA | 80% | ＞0.5 | 3 years | Plastic/ IP66 | D30*20mm | 27g |
| NC-4350-LC1 | 6-13Vdc | 350mA | ||||||||
| NC-4700-LC1 | 3-6Vdc | 700mA | ||||||||
| NC-7180-LC1 | 7W | 200-265V | 24-42Vdc | 180mA | 80% | ＞0.9 | 3 years | Plastic/ IP66 | D41*20mm | 50g |
| NC-7350-LC1 | 14-21Vdc | 350mA | ||||||||
| NC-7700-LC1 | 7-10Vdc | 700mA | ||||||||
| NC-15300-LC1 | 15W | 200-265V | 38-50Vdc | 300mA | 85% | ＞0.9 | 3 years | Plastic/ IP66 | D51*20mm | 80g |
| NC-15350-LC1 | 24-42Vdc | 350mA | ||||||||
| NC-15700-LC1 | 14-21Vdc | 700mA | ||||||||
| NC-3350-LC4 | 3W | 200-240V | 6-12Vdc | 350mA | 75% | ＞0.5 | 3 years | Plastic/ IP66 | 50*27*20mm | 22g |
| NC-4700-LC4 | 4W | 3-6Vdc | 700mA | |||||||
| NC-3300-LC5 | 3W | 200-240V | 6-12Vdc | 300mA | 75% | ＞0.5 | 3 years | Plastic/ IP66 | D25*22mm | 22g |
| NC-3600-LC5 | 3W | 2-4Vdc | 600mA | |||||||
| NC-12300-LC5 | 12W | 180-265V | 21-42Vdc | 300mA | 78% | ＞0.5 | 2 years | Plastic/ IP20 | D68*25mm | 40g |
| NC-24300-LC5 | 24W | 45-82Vdc | 300mA | |||||||
| NC-30230-LC5 | 30W | 80-140Vdc | 230mA |
