Raymond Grinding Mill
Raymond Grinding MillIntroduction:
This
Raymond Grinding Mill is widely used in
barite, calcite, carborundum, silicon carbide, potassium feldspar,
marble, limestone, dolomite, fluorite, lime, titanium dioxide,
activated carbon, bentonite, kaolin, white cement, calcium
carbonate, gypsum, glass, manganese, titanium, refractory
materials, insulation materials, coal gangue, carbon black, coal,
clay, talc, shell, resin, ferric oxide, hong huang dan, quartz,
petroleum coke with hardness less than 7 humidity, in more than 500
in charge of flammable and explosive materials powder processing
under 6%, the product size can be adjusted in the range of 60-325
mesh, part of the material up to 1000 mesh.
Raymond Grinding MillTechnical
Parameter:
| Model | Roller Number(pcs) | Mill Roll Size(R*Hmm) | Size and Height of Grinding Ring(mm) | Maximum Feed Length(mm) | Product Granularity(mm) | Capacity(t/h) | Motor Power(kw) |
| 3R1510 | 3 | 150*100 | 480*100 | 15 | 0.2-0.044 | 0.3-1 | 7.5 |
| 3R2615 | 3 | 260*150 | 780*150 | 20 | 0.2-0.044 | 1-1.5 | 18.5 |
| 3R2715 | 3 | 270*150 | 830*150 | 20 | 0.2-0.044 | 1-3 | 22 |
| 3R3016 | 3 | 300*160 | 880*160 | 20 | 0.2-0.044 | 1-4 | 30 |
| 3R3018 | 3 | 300*180 | 990*180 | 20 | 0.2-0.044 | 3-5 | 30 |
| 4R3216 | 4 | 320*160 | 1073*160 | 25 | 0.2-0.044 | 2-6 | 37 |
| 4R3220 | 4 | 320*200 | 1075*200 | 25 | 0.2-0.044 | 2-7 | 37 |
| 5R4119 | 5 | 410*190 | 1300*190 | 35 | 0.2-0.044 | 2-8.5 | 75 |
| 5R4121 | 5 | 410*210 | 1300*210 | 35 | 0.2-0.044 | 3-9 | 75 |
| 5R4125 | 5 | 410*250 | 1300*250 | 35 | 0.2-0.044 | 5-10 | 75 |
| 6R4528 | 6 | 450*280 | 1600*280 | 40 | 0.2-0.044 | 3-16 | 132 |
