3K Twill Weaving Carbon Fiber Fabric 220gsm By Sichuan Chang Yang Composites Company Limited,

3K Twill Weaving Carbon Fiber Fabric 220gsm

离岸价格

获取最新报价

17.4 ~ 22.5 USD / ( Negotiable )

50 Square Meter Minimum Order

国家:

China

型号:

CCY-3K-T200-1000

离岸价格:

17.4 ~ 22.5 USD / ( Negotiable )（面議）获取最新报价

位置:

最小订单价格:

17.4

最小订单:

50 Square Meter

包装细节:

Standard Export Carton Box and Pallet

交货时间:

10-15days

供应能力:

100000000 Square Meter per Month

付款方式:

T/T, L/C, D/A, D/P, Western Union, Money Gram, PayPal, Other

產品組 :

Carbon Fiber Products

产品规格

Brand Name: CYC
Application: Carrier of Chemical Activator
Shape: Carbon Fiber Fabric
Dimensions: 3K Twill Weaving Carbon Fiber Fabric 220gsm
Product Type: Carbon Fiber Cloth
C Content (%): 100
Working Temperature: 800DC

详情

Carbon Fiber Fabric Specifications:
Sichuan Chang Yang Composites Company Limited weaving smoothly and high quality of Carbon Fiber Fabrics for Aerospace Industry, Military Industry and Civil Industry many years with mature carbon fiber weaving technology.
Carbon Fiber Density: 1k, 3k, 6k, *2k
WeavingPattern: Twill Weaving, Plain Weaving, Satin Weaving, Unidirectional Weaving

1.Carbon Fiber Fabric Description

Weaving Pattern	Twill
Carbon Fiber Density	3K
Roll Width	***0mm
Roll Length	**0m
Areal Weight	**0g/m² (6.3oz)
Thickness	*0.8mm**

2.Carbon Fiber Fabric Packing

Packing	**0sq.m/ctn
Measurement	08**8cm
G.w./N.w.	7/2kgs

3.Carbon Fiber Fabric Application and Model Number
•   Aftermarket Car Parts
Hoods, spoilers, bumpers, dash, etc.
•   Marine
Canoes, kayaks, paddles, oars, etc.
•   Sporting Goods
Bike frames, snowboards, skateboards, hockey and lacrosse shafts, golf clubs, etc.
•   Other applications
Rotor blades, gears, radio-controlled cars and planes, etc.

Model Number	Weaving Pattern	Areal Weight (g/sq.m)	Carbon Fiber Yarn		*Fiber Counts (/0mm)**		Thickness (mm)
Model Number	Weaving Pattern	Areal Weight (g/sq.m)	Warp	Weft	End Count	Pick Count	Thickness (mm)
*CCY3K-P*****0	Plain	**0	3K	3K	4	4	*0.3**
*CCY3K-P*****0	Plain	**0	3K	3K	4.5	4.5	*0.4**
*CCY3K-P*****0	Plain	**0	3K	3K	5	5	*0.5**
*CCY3K-T*****0	Twill	**0	3K	3K	5	5	*0.5**
*CCY3K-P*****0	Plain	**0	3K	3K	5.5	5.5	*0.8**
*CCY3K-T*****0	Twill	**0	3K	3K	5.5	5.5	*0.8**
*CCY3K-P*****0	Plain	**0	3K	3K	6	6	0.3
*CCY3K-T*****0	Twill	**0	3K	3K	6	6	0.3
*CCY3K-P*****0	Plain	**0	3K	3K	6.5	6.5	*0.2**
*CCY3K-T*****0	Twill	**0	3K	3K	7	7	*0.4**

4. More products
1.The Carbon Fiber Fabric twill weaving pattern could be 2*2, 3*3, 4*4. 
2.Standard Carbon Fiber Fabric width is ***0mm; any other width can be produced on your request.
3.Standard Carbon Fiber Fabric roll length is **0meters, *0meters/roll is also available. 
4.Other Carbon Fiber Fabric Areal Weight is also available based on

国家:	China
型号:	CCY-3K-T200-1000
离岸价格:	17.4 ~ 22.5 / ( Negotiable ) （面議）获取最新报价
位置:	-
最小订单价格:	17.4
最小订单:	50 Square Meter
包装细节:	Standard Export Carton Box and Pallet
交货时间:	10-15days
供应能力:	100000000 Square Meter per Month
付款方式:	T/T, L/C, D/A, D/P, Western Union, Money Gram, PayPal, Other
產品組 :	Carbon Fiber Products
