1.high accuracy ball bearing guide screw of taiwan,minimize the
slit.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the
power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is suitable for advertisement.
Performance
Spindle Power 1.5KW water cooling spindle
Spindle Speed 0-24000r/min
X,Y,Z axies working size 600*900*120mm
X, Y ,Z axies Transmssion Taiwan TBI ball screw
Guide rail Taiwan Hiwin square guide rail
Drive Mode Stepper motor and leadshine driver
Control System PCI Nc-studio System
(Option: DSP offline,Mach3 control system )
Design software Artcam
Options:(Type3 , Ucancam, JDPaint , Mach3 )
Max.Traveling Speed 32000mm/min
Max. Working Speed 12000mm/min
Repositioning precision ±0.03mm
Mechanical precision 0.05mm
Command G Code, *uoo, *mmg, *plt
Suitable tools dimeter ER11
3.175mm 4mm 6mm
Working Voltage AC220V , 50/60Hz, single/3 phase // 380V 3
phase
Warranty 1 year for the mahcine ,half year for the spindle
Certificate CE FDA ISO9001
