Air Screen Cleaner
Air Screen Cleaner Introduction
The 5X series Air Screen Cleaner is a universal machine well suited for pre- and fine cleaning many different species of grain and seeds.
The standard design of the machine is provided with both pre- and after suction units.
Quick screen changing from pre-cleaning into fine cleaning by the operator serves to optimize the cleaning tasks.
The 5X series air screen cleaner is a very competitive machine, both as regards price and capacity as well as function and operation.
Easy and quick operation and screen changing
The screen boxes are made of wear resistant plywood, which is approved for food
Screen cleaning with special rubber balls
Built-in light.
Durable surface of the machine owing to high-quality powder
lacquering
Air Screen Cleaner Technical data
|
Model |
5X-5 |
5X-12 |
|
Dimension(L×W×H) |
3200×1920×3600 mm |
3790×1940×4060 mm |
|
Overall weight |
3250 kg |
3600 kg |
|
Rated capacity |
5 t/h |
12 t/h |
|
Overall air volume |
8200 m3 |
12520 m3 |
|
External air blower |
4-72N0-6A, 7.5 kW |
4-79N0-6A, 11kw |
|
Vibration sieve motor(gear motor) |
2.2 kW |
2.2 kW |
|
Back lifting system motor |
3.0 kW |
3.0 kW |
|
Feeding motor |
1.5 kW |
1.5kw |
|
Total Power |
6.7 kW |
6.7kw |
|
Air Blower Type |
centrifuge air blower |
|
|
Top air blower Rotary speed |
4-79NO6A,1400 r/min |
|
|
Back lifting air blower Rotary speed |
100~1000 r/min |
|
|
Screen Type |
piercing screen |
|
|
Screen Dimension (L×W) |
800×1250 mm |
|
|
Frequency |
|
|
| 国家: | China |
| 型号: | 5X-12 |
| 离岸价格: | 24800 ~ 25000 / Set ( Negotiable ) 获取最新报价 |
| 位置: | - |
| 最小订单价格: | 24800 per Set |
| 最小订单: | 1 Set |
| 包装细节: | packing film |
| 交货时间: | 30 days |
| 供应能力: | 10 Set per Week |
| 付款方式: | L/C, T/T |
| 產品組 : | Fine Seed Cleaner |
