CHINA symons cone crusher for sale --china hymak

详情

The cavity designed by crushing principles is perfectly cooperating with the fast gyrating of head, which makes S series cone crushers:
lThe crushing materials in cavity, with the huge impact and pressure caused by the head, cost low resources with high efficiency.
lCrushing materials in the cavity being crushed continuously while discharging products at the same time with gravity.
lThrough 3 to 5 times crushing activities, crushing materials are being rearranged during the process of falling and bumping, which causes better shapes of final products;
Large Broken Pressure:
Compared to other types of cone crushers, S series cone crushers are with longest arm of crushing force，so that
The broken pressure which is forced to the cavity is big;
The force being conducted by eccentric to main shaft is low, and this makes the rise of temperature quite low and thus ensures a long life.
 High Yield :
Compared to other types of cone crushers, S series is with the biggest gyrating stroke, and thus cause a higher out put, blow are the detailed reasons:
It has the ability to conduct crushing materials more effectively, with more crushing materials in each gyrating stroke;In each gyrating stroke, the distance which the head moving opposite to bowl liner is big enough to let in more crushing materials to get into cavity, forming a larger volume of crushing material, so that the speed that the crushing materials passing is much faster;
lBoth standard head cone crusher and short head cone crusher can fully reach the capability of crushers by giving full feed in cavity.Low Daily Operation and Maintenance Cost:
Proper choice of structural design and materials prolong the life of the equipment greatly;
Longer arm of crushing force decreases the burden of sliding bearing, gears and main frame;
The size of final products is even which reduces the burden of circulation;
High reliability of anti-iron system and it attributes a lot in the reducing of burden.
The cleaning system of hydraulic pressure is easy to control, decreasing the time of maintenance.The major difference between standard head and short head is the difference in cavity.
Standard Head**-Allowance of larger size of feed, and it enables the customers to conduct first time or twice crushing process according to the practical situation. Each type of standard head cone crushers includes 4 different cavities which are fine, media, coarse and extra coarse.
Short Head**-With a relatively deep head, the parallel space of cavity is longer, if the feed size is small, then the finer final products are produced. It can be conducted as the second or third time crushing process. The same to standard head, each type of short head cone crushers includes 4 different cavities which are fine, media, coarse and extra coarse.
