Main Specifications:
| Parameter | Unit | Value | |||||
| Channels Number | - | 4 | 8 | ||||
| Min. | Typ. | Max. | Min. | Typ. | Max. | ||
| Channel Space | nm | 20 | |||||
| Central Wavelength | nm |
1271/1291/1311/1331/1351/1371/1391/1411/1431/ 1451/1471/1491/1511/1531/1551/1571/1591/1611 |
|||||
| Operating wavelength | nm | 1260-1460 or 1460-1620 or 1260-1620 | |||||
| Passband | nm | λITU±6.5 | |||||
| CWDM Channel Insertion Loss | dB | 0.8 | 1.3 | 1.5 | 1.0 | 2.2 | 2.8 |
| Adjacent Channel Isolation | dB | 30 | - | - | 30 | - | - |
| Non-adjacent Channel Isolation | dB | 40 | - | - | 40 | - | - |
| Polarization Mode Dispersion | ps | - | - | 0.2 | - | - | 0.2 |
| Polarization Dependent Loss | dB | - | - | 0.2 | - | - | 0.2 |
| Return Loss | dB | 40 | 45 | - | 40 | 45 | - |
| Directivity | dB | 50 | 55 | - | 50 | 55 | - |
| Insertion Loss Temperature Sensitivity | dB/°C | 0.005 | - | - | 0.005 | - | - |
| Wavelength Temperature Shifting | nm/°C | 0.002 | - | - | 0.002 | - | - |
| Power (max.) | mW | - | 300 | 500 | - | 300 | 500 |
| Operation Temperature | °C | -10~+70 | |||||
| Package Dimension | mm | 50×28.8×6.5 or customized | |||||
| 国家: | China |
| 型号: | - |
| 离岸价格: | ( Negotiable ) 获取最新报价 |
| 位置: | - |
| 最小订单价格: | - |
| 最小订单: | 1 Piece |
| 包装细节: | Carton |
| 交货时间: | 1 week |
| 供应能力: | 1000 Piece per Day |
| 付款方式: | Western Union, L/C, T/T |
| 產品組 : | CWDM mux/demux |
