Crystalline Silicon Solar Cell/Wafer Scribing Machine

离岸价格

获取最新报价

1 Minimum Order

国家:

China

型号:

CYS-50D

离岸价格:

（面議）获取最新报价

位置:

最小订单价格:

最小订单:

包装细节:

交货时间:

供应能力:

付款方式:

產品組 :

现在联系

查看手册

Zhuhai Choye Laser Machinery Co LTD

China

免费会员

联系人 Ms. donna

Taidong Street No.107, ZhuHai, Other

现在联系

产品规格

详情

Product introduction

CYS**0D

The laser scribing machine is specialized in solar cell/wafer scribing/cutting on solar PV module manufacturing. CYS**0D laser scribing machine from Choye Laser is configured with advanced DPSS(diode-pumped solid-state) laser module, continuous wave, Q-switched, which ensures excellent beam quality for getting smooth and level cell edge. Obvious advantages over conventional lamp-pumped laser system.

Product Features

1. all-in-one DPSS laser module, no consuming part, free of maintenance on optic system.(lamp-pumped laser: consuming part-krypton lamp, replaced for three to six months)

2. better beam quality: thinner scribing kerf, smoother scribing cell edge, less cell loss.

3. energy-saving. 2kwh consumption. (lamp-pumped laser: 6kwh consumption)

4. laser chiller: independentcooling system, intellectcooling, compact and easy to move.(lamp-pumped laser: air-conditioning outside unit, hard to move)

5. compact volume: 1.8 m3 , easy to place. (lamp-pumped laser machine: 3.6 m3)

6. friendly operating interface, software easy to learn & control.

Product Parameters

Model	CYS**0D
Laser	Diode-pumped solid-state laser module, pulsed ***4 nm
	Q-switch made in the US
	Output power:0 W, max. 5W
	Frequency: adjustable, 0.5 - *0 kHz
	Aiming laser: Red
Scribing	Max thickness 1.2 mm (Silicon)
	Max axis speed: **0 mm/s
	Min kerf width: 0.*4 mm
Moving system	X-Y axis, granite substrate, working area: 0 mm × 0 mm
	Manual loading/unloading
	Ball screw/lead rail/slide block made in Taiwan, accuracy: 0.*1 mm
Other info	Power supply: -phase -wire *0 VAC+/- 0%, 0 Hz, max 2 kW*
	A voltage stabilizer might be required to avoid irregular scribing quality caused by severe voltage fluctuation
	Dimension: *0(L) × 0(W) × ***0 (H) mm
	Gross weight: **0 kg
Configuration	Diode-pumped laser module × 1 set
	Scribing software (In English) × 1 set
	Chiller × 1 set
	Operation manual (in English) × 1 set
	Exhaust fan × 1 set
	LED display × 1 set
	Worktable unit (CNC) × 1 set

Application:

Specialize in solar PV module/panel manufacturing: mono/poly crystalline solar cell laser scribing, silicon wafer cutting, film solar cell scribing, ect..

Cutting edge view:

Warranty and services

One-year conditioned warranty: During the warranty period, Choye Laser offers free replacing parts/services if the machine has defects; If the machine damage is due to false operation, the replacing parts/services shall be charged; After warranty period, Choye Laser provides life-time maintenance/services/spare parts and they shall be charged.
