Feature:
a. To granulate
radial tires into finerubber powderwith steeland fiber completely recycled at ambient
temperature.
b. The whole
tires, after the processing, steel are completely separated
and fiber can be separated up to *9% or above.
c. The finish
product is high and competitive in the market
d. Tight
construction, small space and simple technique flow.
e. Low
energy-consuming,Low
energy consuming and good performance-cost
ratio
f. High
autoimmunization, fewer labors requirement.
g. Unique design,
high output and long lifetime blade characterize secondary
shredder and fine rubber shredder, which can improve the working
efficiency and lower equipment maintenance cost.
h. In line have dust
remover, equipment running pollution-free, no fine dust, no fiber
fly in the shop, meeting the environmental requirement of the
government.
Application:
A. sports ground
Track field, school play ground,
swimming pool around, garden alleys, bowling ground, kindergarten
ground, gaming ground, tennis and basketball ground, etc.
B. auto industry
Road belt for busy area, safety
belt, steeling wheel cover, brake sleeve, sealing strip, buffer,
mud defender, tire interleave.
C. building and
equipment
Binding and sealing material,
hospital, company, bathroom floor, insulation material,
under-mat, livestock mat, pressing material, casting material,
printing, dam, warehouse, pool, and waste material disposing
station, house covering and sealing, signboard, water material,
rubber sheet, shaking proof material, ring mat, rooftop and wall
waterproofing material.
D. construction and
asphalt
drain pipe, rubberized asphalt,
filter, earth modulation and surface covering, washing water
pipe, railway crossing, auto& walkway signing obstacle, stuff
at railway joint and road cracks, daily maintenance material at
shipping industry.
E. Rubber recycling
Various rubber products.
F. Other application
Coating, pain, adhesive, activated
carbon.
Other Notes:
Minimum Order Quantity: 1
set.
Delivery Time: about *0
normal working days after we received the advance.
Package: packing with film or
wooden case(according to customers' request).
Guarantee: We provide
one-year warranty for all the machine.
Service: life-time for all the
spare parts.
1,Tire debeader
The first step in tire
recycling procession
Heavy duty
body
Hooks and cross pulling die
made of *5# steel, tempered and quenched
Equipped with protection
frame avoiding the dangers during working
Two series: hydraulic one
and mechanic one
Easy to operate and change
spare parts (hooks and cross pulling die)
2,Tire cutter
Cutting tires into pieces before
shredding
Small tire pieces are easier to process in
shredder
Knives made of YG**0 steel, long using
time
Hydraulic control
One clamping cylinder and one cutting
cylinder
Equipped with a roller platform to process
big tires
3,Tire shredder
The high-capacity shredder was specially
developed for direct size reduction of tires into cleanly cut tire
chips, size *0x*0 mm. cutting shafts for the production of larger
tire chips are available high torque at low
speed cut even the strongest tires into
pieces. All
construction characteristics are designed for continuous operation
in order to achieve highest throughput rates at lowest
costs. Extremely
precise tolerances between the cutting knives produce cleanly cut
tire chips at low energy consumption.
The cutting knives made of high quality alloy
steel can be re-sharpened and reused which increases the service
life and reduces the operating costs.
The complete cutting chamber is lined with
hard wear plates. Large
doors allow for easy access into the cutting chamber.
4,Tire
cracker
Emergency stop when
overload Distance
between the two rollers can be adjusted.
Hard gear gearbox
Equipped with screening machine, magnetic
separator and fiber separator, *9% purified rubbers will be
got. Finals: ***0
mesh 5,Magnetic
separator
6,Fiber separator
7,Pulverizing unit
The pulverizing unit is made of 3 sets
pulverizers with a cyclone silo.
The pulverizer
consists of frame, main motor, non-pole reducer, feeding device,
adjusting device and a pair of rotating disc and fixed
disc. The fine powders will be achieved by the
grinding and shearing of the two pin discs.
The machine is
cooled by water and air to ensure the quality of the
powders. Non-pole reducer can adjust speed of the feeding
device to meet the material demands.
The cyclone
silo will collect the rubber power without dust
Finals: ****0
mesh After the
grinder, the nylon wires will be grinded into fluff; According to
centrifugal force, density difference, the fluff will be
separated. The spin fans
inside the cyclone barrel driven by the motor throw the compounds
to the wall, at this time, light fluff will be upwards and fall
down into the inside barrel; heavy rubbers will fall down directly,
so textiles will be separated
Muti-stage belt style magnetic separator can
reach more purified rubbers
Separated steels will be in one place, easy
to collect Permanent
magnet, no more power consumption
The shear between the two
rollers will make tire chips into powders as well loosen rubbers,
steels and textiles Roller body made of cast
steel Surface of roller made of
alloy steel, welded when worn out
One flat surface roller
and one teethed roller, high throughput of
powders Bottom made of cast
iron
| 国家: |
China |
| 型号: |
odf
|
| 离岸价格: |
（面議）
获取最新报价
|
| 位置: |
Shandong China (Mainland) |
| 最小订单价格: |
- |
| 最小订单: |
1 Set |
| 包装细节: |
Wooden case packing, apply to maritime navigation |
| 交货时间: |
35 working days |
| 供应能力: |
1000 Set per Month |
| 付款方式: |
T/T, L/C, Western Union |
| 產品組 : |
ring cutter
|
