Product Description
RKE 1900 Automatic Vision Inspection Machine for Pin
Optical Sorting Inspection Device
This machine adopts vibration disc feeding, equipped with artificial intelligence visual inspection software, and equipped with 8CCD industrial cameras.

According to customer requirements, it can detect whether the key dimensions of the product, such as inner diameter, outer diameter, height, etc., meet the drawing requirements, as well as whether the surface of the product has appearance defects such as upper and lower surface cracks and burrs.The detection speed is 100pcs/min, and the detection accuracy is ± 0.02mm.


Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device
Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device
Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device

Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device
Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device
Rk 1900 Glass Plate Visual Inspection Solution for Pin Optical Sorting Inspection Device

Thank you for your trust in RKE Intelligent Technology Co., Ltd. We will provide you as following:
Item Specification

Optical Sorting Machine
       RK-1900-C8
  1. Inspection Component: size / appearance defective
  2. Camera : Hi-Vison Color CCD (200w)
  3.  Light Source: RGB cascade multi-angle LED combination lighting, high brightness, 2M pixels tele-centric lens, 50*50mm
  4.  Motor : Japan Panasonic
  5. Computer: Dell 2.7G, DDR II 2.0G, 500G , 19" wide screen LCD
  6. Software: RKE self-developed(based on labview)
  7. Solenoid valve: American Newmandick solenoid valve
  8. Power: 220V/50Hz ,1000W
  9. Accuracy :  ± 0.02mm
  10.  Detect Speed : 100pcs/min
  11. Machine  size: 1100*1000*1860(2150)mm,Weight: 355KGS
  12. Vibrating Device  size: 650*800*1350mm, Weight:  255kgs
