Flotation cell can be often seen in ore dressing factory, which is applied for sorting non-metallic material, and which is one important flotation plant. And what's more, flotation concentrator can be used for sorting the metal material including copper, lead and gold. And flotation cell is also being called flotation separator, flotation machine and flotation-cell.

The working principle of flotation cell: The mineral pulp being added pharmacy will be passed into the gas, and the electric rotor will bring the movement of part pieces to mix and stir in order to make the mineral and gas be sufficiently mixed, and at this minute, the grain of mineral pulp is above on the bubble, floating on the surface, which can reach the purpose of sorting the mineral material through blade scrapings.
This machine is often used in the flotation process of mineral ore.

Flotation separation process: It refers to the flotation process in particular; the flotation process of every material is different, because some mineral material has the higher combination ability with the water, which is difficult to be above on the bubble. We must inspect and examine the mineral ore before selection, and ore much be classified by grinding in order to reach one suitable density and fineness of flotation process.

Hongxing mining machinery majors in producing the ore flotation equipment. Welcome to have a visit and purchase some machines that you need.
 This type of flotation machine is formed by U through solid, hollow shaft inflation, suspension rotor and new type impeller. The cone impeller lean backwards, the blending quantity is big and the pressure head is small, the advantages are: simple structure and low energy consumption. Inside the impeller, there is air distributor, which distributes air into most parts of impeller evenly.
    When flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers. Meanwhile, the low pressure air send by fan is sent to this area through the air distributor in the hollow shaft. After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough. When the froth rises to the stable level, after the enrichment processing, froth overflows to the froth trough from the overflow weir. Another part of ore slurry flows to lower part of impeller for the re-mix with air. The remained slurry flows to the next trough until becomes residue.

Main Technical Parameters:
SF Series:
