High Quality Heating Sleeve

国家:

China

型号:

ZNHW, ZNHW-II, PTHW

离岸价格:

500 ~ 1000 / Piece ( Negotiable ) （面議）获取最新报价

位置:

最小订单价格:

500 per Piece

最小订单:

1 Piece

包装细节:

Wooden box

交货时间:

within 15 days after placing the order

供应能力:

10000 Piece per Year

付款方式:

PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T

產品組 :

Heating Sleeve

现在联系

产品规格

Brand Name : Honghua Classification : -

Place of origin : China Certification : CE

详情

General Introduction：
Electronic temperature control electric heating sleeve machine is widely used in large and medium-sized institutions, heating the liquid petroleum, chemical, pharmaceutical, environmental protection and other industries in the laboratory. It uses alkali free glass fiber insulating material resistant to high temperature, the material nichrome resistance wire is sealed in an insulated layer woven into a hemispherical internal heating type heater, and has the advantages of large heating area, quick temperature rise, no open flame, uniform heating, energy security and other.
MainFeatures:
1. Light-weight insulated materials can be shaped into hemispherical heat Insulator by high voltage with high temperature resistant plastic casing, or casing with structural steel cold rolling plate baked enamel or electrostatic spray.
2. It is beautiful in appearance, light in refitting, constant temperature controlling with standard shape and durable using.
Detail Characteristics:
1. Silicon controlled voltage regulating with high power, regulate the temperature into constant temperature by combing control wiring of relay with electric contact thermometer, dispensing with variac.
2. Required temperature, keep constant temperature.
3. TW type: temperature regulating type.
4. SX type: digital display type.
5. Monolithic processor controls, multiple digital filtering circuit, PID control mode, accurate temperature controlling.
6. Operate by lightly touch single bond, dual screen display, double thermocouples measure the internal and external temperature.
7. Silicon controlled controls output and short circuit protection function.
ZNHW-II

Model	ZNHW-II
Capacity (ML)	50	100	150	250	500	1000
Voltage (V)	220V, 50Hz
Power (W)	110	130	170	216	220	530
Temp. Range (℃)	Ambient to 380
Working Time	Continuous
Upper Diameter（mm）	58	75	81	95	115	145
Exterior Dimensions（cm）	20*14	20*14	20*14	23*15	23*15	26*16
Net Weight（Kg）	1.1±0.05	1.2±0.05	1.2±0.05	1.3±0.05	1.3±0.05	1.5±0.05
Shell Material	ABS Plastic, anti-aging, anti-corrosion
Insulating Course Material	Environment Alumina Silicate Fiber
Insulating Barrier Material	Alkali-free glass fiber, Max Temperature Resistance 450℃

ZNHW Series:
Features:
1. 9 series mantles sizes available from 100 ml to 20liter.

2. Directly heating, more easy, temperature uniformity.

3. Built-in temperature control maintains element temperature from ambient to 400°C.
Main Parameter

Model	ZNHW
Capacity (L)	2	3	5	10	20	50
Voltage (V)	220V, 50Hz
Power (W)	650	730	1100	2100	3000	6000
Temp. Range (℃)	Ambient to 380
Working Time	Continuous
Upper Diameter（mm）	180	212	253	305	384	475
Exterior Dimensions（cm）	27.5*19	30*20	34*23	40*26	48*30	58.5*47.5
Net Weight（Kg）	2.93±0.1	3±0.2	4.55±0.4	6.85±0.5	8.35±0.2	28.2±0. 5
Shell Material	Superfine metal, anti-aging, anti-corrosion
Insulating Course Material	Environment Alumina Silicate Fiber
Insulating Barrier Material	Alkali-free glass fiber, Max Temperature Resistance 450℃
